Vertiv PowerIT VP4U62A0 power distribution unit (PDU) 24 AC outlet(s) 2U Black

rack power distribution unit, 14.4kW, 1P+N+E (IP44), TAA Compliance, RoHS, China RoHS, UL/CE dual listed, 3-year warranty extending to 5-year warranty if registered within 120 days of purchase

Key Features

• Seamlessly upgrade your rPDU with the hot-swappable Interchangeable Monitoring Device (IMD-5M)
• Connect both C14 and C20 plugs interchangeably via the Combination C13/C19 receptacle
• Secure connections with the high-retention, color-coded receptacle that is P-Lock cable-compatible
• Streamline deployment of up to 50 devices on a single IP address with Vertiv Intelligence Director
• Comes with a three-year warranty, extendable to five years if registered within 120 days of purchase

Description

The Vertiv PowerIT Monitored High Density Rack Power Distribution Unit (rPDU) VP4U62A0 is an upgradeable, 60/63A, 240V, 2U, horizontal rPDU with input monitoring. It has 24 Combination C13/C19 outlets that provide the flexibility to connect C14 and C20 plugs in the same outlet interchangeably. This unit also comes with a 1P+N+E (IP44) plug providing 14.4kW of power capacity. The hot-swappable Interchangeable Monitoring Device (IMD-5M) has ports for serial communication and environmental monitoring, while the dual gigabit ethernet ports simplify the management of multiple PDUs with fault-tolerant daisy chaining or IP aggregation capabilities. This model is UL/CE dual listed, meeting an important requirement for data centers. It is also RoHS-certified and individually tested for functionality to ensure your network is powered by a reliable power distribution unit. Plus, it includes a three-year warranty that is extendable to five years if registered within 120 days of purchase.

Specifications

Design
Type	Single-phase
PDU types	Monitored
Mounting	Horizontal
Product colour	Black
Certification	UL Listed, RCM Mark(EMC Only), CE Marked, UKCA Marked, Complies with IEC 62368-1
Rack capacity	2U
Ports & interfaces
USB ports quantity	1
AC outlets quantity	24 AC outlet(s)
AC outlet types	C13 coupler, C19 coupler
Power plug	Type E / Type F
Serial ports quantity	1
Features
Cable length	120" (3.05 m)
Certification	UL Listed, RCM Mark(EMC Only), CE Marked, UKCA Marked, Complies with IEC 62368-1
Management features
Management platform	DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+
Ergonomics
Cable length	120" (3.05 m)
Power
Maximum power	14400 W
Nominal input voltage	240 V
Power protection features	Over current
Maximum current	63 A
Certificates
Certification	UL Listed, RCM Mark(EMC Only), CE Marked, UKCA Marked, Complies with IEC 62368-1
Compliance certificates	China RoHS, Trade Agreements Act (TAA), RoHS
Weight & dimensions
Weight	19 lbs (8.62 kg)
Width	17.1" (434.7 mm)
Depth	12" (304.8 mm)
Height	3.48" (88.4 mm)
Package width	30" (762 mm)
Package depth	26" (660.4 mm)
Package height	4" (101.6 mm)
Package weight	19 lbs (8.62 kg)
Packaging data
Package width	30" (762 mm)
Package depth	26" (660.4 mm)
Package height	4" (101.6 mm)
Package weight	19 lbs (8.62 kg)
Technical details
Compliance certificates	China RoHS, Trade Agreements Act (TAA), RoHS
Logistics data
Country of origin	United States
