StarTech.com D86A2-2-PORT-8K-KVM KVM switch Black

StarTech 2-Port DisplayPort KVM Switch, 8K 60Hz / 4K 144Hz, Single Display, DP 1.4, 2x USB 3.0 Ports, 4x USB 2.0 HID Ports, Push-Button & Hotkey Switching, TAA Compliant (D86A2-2-PORT-8K-KVM)

Key Features

• 8K 60HZ WITH HDR: Fast switch between two USB-A and DisplayPort-enabled desktops to share a keyboard, mouse, audio device, and a single 8K 60Hz DisplayPort monitor; DSC support required for maximum video performance; Supports MST Pass-through
• UNIVERSAL COMPATIBILITY: TAA-Compliant KVM Switch works with any operating system including Windows, macOS, ChromeOS, and Linux; Compatible with all hardware platforms such as Intel and AMD; Supports ultrawide resolutions up to 5120x1440 60Hz
• MULTIPLE SWITCHING OPTIONS: Fast Switching via push-buttons or hotkeys with an audible buzzer providing confirmation; LEDs provide quick visual port selection status; Listen to audio from one computer while controlling the other
• THOUGHTFUL DESIGN: Metal housing is durable and helps prevent Electro-magnetic Interference (EMI); Overcurrent Protection (OCP) prevents peripherals from overdrawing power, reducing the risk of damage to the KVM and attached USB devices
• TECHNICAL SPECIFICATIONS: KVM Switch is DisplayPort 1.4 compliant, supporting resolutions up to 8K 60Hz or 4K 144Hz, HDR10, HDCP 2.2/1.4, and DSC; Supports DisplayPort Audio and 3.5mm analog audio; USB 5Gbps Hub Ports; OS Independent

Description

Share a mouse, keyboard, USB 5Gbps Hub, and 8K 60Hz DisplayPort between two DisplayPort enabled computers

Share and switch between two USB-A and DisplayPort-enabled computers, using this DisplayPort KVM Switch. Share an 8K 60Hz DisplayPort monitor, a keyboard and mouse, two USB 5Gbps devices, and two additional USB 2.0 devices.

High-Resolution 8K 60Hz Video

This KVM supports resolutions up to 8K 60Hz or 4K 144Hz/120Hz. Daisy chain additional monitors via MST pass-through. The KVM supports ultrawide resolutions of up to 5120x1440 at 60Hz. Ideal for applications such as CAD/CAM, video editing, and content creation. Support for High Dynamic Range (HDR) offers increased contrast, brightness, colors, and greater luminosity.

Customizable Switching

This Universal KVM Switch provides various switching options, including hotkey or push-button switching. Hotkeys allow for independent switching of audio and video, enabling audio playback from one computer while controlling the other. An audible buzzer confirms hotkey input, and LEDs provide a visual status of the selected host.

Universal Compatibility

The TAA-Compliant KVM Switch offers universal compatibility, working with all operating systems, including Windows, macOS, ChromeOS, and Linux. It is also compatible with all hardware platforms, including Intel and AMD.

Reliable Performance

The durable metal housing helps prevent Electro-magnetic Interference (EMI). Overcurrent Protection (OCP) ensures peripherals don't overdraw power, reducing the occurrence of device dropouts or shutdowns.

Specifications

Ports & interfaces
Console USB ports quantity	6
Console ports	3.5mm headphone, DisplayPort, USB A
DisplayPorts quantity	2
DisplayPort version	1.4
Number of computers controlled	2
Keyboard port type	USB
Mouse port type	USB
Video port type	DisplayPort
Audio connections	Yes
Headphone outputs	3
DC-in jack	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity	2
Console DisplayPorts ports quantity	1
HDCP	Yes
Performance
Daisy chain	No
Chipset	GL-3523
HDCP	Yes
Data transfer rate (max)	5 Gbit/s
HD type	8K Ultra HD
Plug and Play	Yes
Maximum resolution	7680 x 4320 pixels
Scan interval	3,8,15,30 s
High Dynamic Range (HDR) supported	Yes
HDCP version	1.4/2.2
Technical details
Product colour	Black
Rack mounting	No
Plug and Play	Yes
Scan interval	3,8,15,30 s
Push button	Yes
On Screen Display (OSD)	No
LED indicators	Yes
Hot keys	Yes
IP control	No
Sustainability compliance	Yes
Compliance certificates	CE, RoHS, Trade Agreements Act (TAA)
Design
Mean time between failures (MTBF)	130000 h
Product colour	Black
Rack mounting	No
Push button	Yes
LED indicators	Yes
Hot keys	Yes
Housing material	Steel
Display
Built-in display	No
On Screen Display (OSD)	No
Power
Input current	1 A
Output current	3 A
Compatible power plug types	EU, JP, UK, US
Output voltage	12 V
Power source	DC
Power consumption (typical)	36 W
Input voltage	100 - 240 V
Video
HD type	8K Ultra HD
Maximum resolution	7680 x 4320 pixels
Sustainability
Sustainability compliance	Yes
Compliance certificates	CE, RoHS, Trade Agreements Act (TAA)
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Weight & dimensions
Width	3.94" (100 mm)
Depth	6.3" (160 mm)
Height	1.57" (40 mm)
Weight	21.2 oz (600 g)
Package width	7.36" (187 mm)
Package depth	9.53" (242 mm)
Package height	3.66" (93 mm)
Package weight	2.2 lbs (1 kg)
Packaging data
Package width	7.36" (187 mm)
Package depth	9.53" (242 mm)
Package height	3.66" (93 mm)
Package weight	2.2 lbs (1 kg)
Packaging content
Rubber feet	Yes
Quick installation guide	Yes
Other features
IP control	No
Push button	Yes
Hot keys	Yes
Logistics data
Master (outer) case width	15.6" (397 mm)
Master (outer) case length	10.1" (257 mm)
Master (outer) case height	11.8" (300 mm)
Products per master (outer) case	60 pc(s)
