StarTech.com Gigabit Ethernet Fiber Media Converter with Open SFP Slot - Fiber to Ethernet Converter - Gigabit Ethernet Media Converter

Description

Convert and extend a Gigabit Ethernet connection over fiber using the Gigabit SFP of your choice

The ET91000SFP2 Open SFP Fiber Media Converter converts and extends a Gigabit Ethernet connection over fiber, using the Gigabit SFP of your choice.

A versatile solution for connecting an Ethernet (1000Base-T) network to remote network segments over a fiber backbone, the media converter features an open SFP slot that lets you choose the MSA-Compliant Gigabit SFP that best suits your fiber connection mode (single / multi-mode) and distance requirements (see our full line of for compatible solutions).

The fiber to Ethernet converter has a durable all-steel chassis and offers simple plug-and-play installation, while support for full-duplex operation and Jumbo Frame support provides efficient network operation.

For added versatility, this Gigabit media converter supports standalone operation, or installation into the 20 Slot, ETCHS2U" text="2U Rackmount Chassis (ETCHS2U). For applications where multiple chassis-mounted media converters are required, this Gigabit media converter can be purchased as a ET91000SFP2C" text="Card Module only (ET91000SFP2C).

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

- Install the SFP of your choice with the open SFP slot
- Operate as a standalone media converter or install into the ETCHS2U chassis
- Ensure maximum up-time with link-loss forwarding and remote status monitoring

Specifications

Network
Converter input interface	1000Base-T
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z
Ethernet LAN data rates	1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Duplex system	Full, Half
Converter output interface	1000Base-LX, 1000Base-SX
Auto MDI/MDI-X	Yes
Maximum data transfer rate	1250 Mbit/s
Fiber optic connector	SFP
Performance
Mean time between failures (MTBF)	65000 h
Features
Housing material	Steel
LED indicators	Yes
Product colour	Black
Internal	No
Ports & interfaces
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Fiber ports quantity	1
Fiber optic connector	SFP
Power
Power over Ethernet (PoE)	No
Input voltage	100 - 240 V
Input current	0.36 A
Output voltage	12 V
Output current	1 A
Power consumption (typical)	8 W
External power adapter	Yes
Weight & dimensions
Width	3.74" (95 mm)
Depth	6.3" (160 mm)
Weight	14.1 oz (400 g)
Height	0.787" (20 mm)
Package depth	8.19" (208 mm)
Package width	5.39" (137 mm)
Package height	3.62" (92 mm)
Package weight	27.7 oz (786 g)
Operational conditions
Operating temperature (T-T)	0 - 60 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Packaging content
Manual	Yes
Packaging data
Package depth	8.19" (208 mm)
Package width	5.39" (137 mm)
Package height	3.62" (92 mm)
Package weight	27.7 oz (786 g)
Technical details
Housing material	Steel
Internal	No
Harmonized System (HS) code	85176990
Compliance certificates	RoHS
Indication
LED indicators	Yes
Design
Housing material	Steel
LED indicators	Yes
Product colour	Black
Certification	FCC
Internal	No
Endurance
Mean time between failures (MTBF)	65000 h
Colour
Product colour	Black
Certificates
Certification	FCC
Compliance certificates	RoHS
Logistics data
Harmonized System (HS) code	85176990
