Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters)

Description

Extend an RS232 serial connection up to 1000 meters (3300 feet) using Cat 5 cabling
The RS232EXTC1 Serial over Cat 5 Extender allows you to increase the distance of your RS232 Serial connection by up to 1000 meters (3300 feet), giving you the ability to connect serial peripheral devices up to a kilometer away from your system - an incredible 65x greater than normal RS232 serial cable length restrictions would permit. The Extender is a cost-effective serial extension solution and completely hardware-based, eliminating the need to install additional software, allowing for a completely plug and play installation. The hardware can be setup in minutes, using existing or new Cat 5 or better Ethernet cabling. Perfect for use in industrial monitoring and control, POS, security, medical, and traffic flow applications, the RS232 Serial over Cat 5 extender maintains the RS232 standard with support for data transfer rates of up to 230 Kbps. Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Provides you with flexibility when choosing the location of your serial peripherals by dramatically increasing the maximum RS232 serial cable length
- Pure hardware design, no software or drivers required ensuring a simple plug and play installation
- Enables use of separate control rooms away from harsh environmental conditions where serial devices may be located

Specifications

Performance
Type	Network receiver
Maximum transfer distance	39370.1" (1000 m)
Cable types supported	Cat5
Network
Cabling technology	10/100Base-T(X)
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
Design
Product colour	Silver
Power
Input current	0.055 A
Output voltage	9 V
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	0 - 85 °C
Operating relative humidity (H-H)	0 - 95%
Weight & dimensions
Width	1.34" (34 mm)
Depth	3.62" (92 mm)
Height	0.866" (22 mm)
Weight	2.29 oz (65 g)
Packaging data
Package width	2.24" (57 mm)
Package depth	12.4" (315 mm)
Package height	5.43" (138 mm)
Technical details
Type	Network receiver
Maximum transfer distance	39370.1" (1000 m)
Cable types supported	Cat5
Compliance certificates	RoHS
Colour
Product colour	Silver
Certificates
Compliance certificates	RoHS
