NetShelter SX, Networking Rack Enclosure, 48U, Black, 2258H x 750W x 1200D mm

Description

An industry standard network rack ready for high density environments with height designed to easily fit through standard doorways. Network rack design enables faster deployment of network switches and an optimized rack mounting space designed specifically for cable and airflow management of large core networking switches and Storage Area Network (SAN) directors. Deeper rack design provides enough rack mounting space for even the deepest devices and still plenty of room for vertically mounting Rack PDUs and cable management. 48U height allows for an additional 6U of rack mounting space maximizing u-space per rack footprint.

Specifications

Features
Size (imperial)	19"
Rack capacity	48U
Type	Freestanding rack
Maximum weight capacity	3756.7 lbs (1704 kg)
Product colour	Black
Certification	RoHS,China RoHS,REACH
Weight & dimensions
Mounting depth (max)	37.8" (95.9 cm)
Mounting depth (min)	11" (27.9 cm)
Width	29.5" (750 mm)
Depth	47.2" (1200 mm)
Height	88.9" (2258 mm)
Weight	408.7 lbs (185.4 kg)
Size (imperial)	19"
Maximum weight capacity	3756.7 lbs (1704 kg)
Technical details
Type	Freestanding rack
Size (imperial)	19"
Dimensions (WxDxH)	29.5 x 47.2 x 88.9" (750 x 1200 x 2258 mm)
Static load	1363.64 kg
Dynamic load	1022.73 kg
Harmonized System (HS) code	85381000
Total carbon footprint (kg of CO2e)	631.68
Rack capacity	48U
Colour
Product colour	Black
Packaging data
Package dimensions (WxDxH)	33.5 x 52 x 93.9" (851 x 1321 x 2385 mm)
Certificates
Certification	RoHS,China RoHS,REACH
Logistics data
Harmonized System (HS) code	85381000
Other features
Package dimensions (WxDxH)	33.5 x 52 x 93.9" (851 x 1321 x 2385 mm)
Dimensions (WxDxH)	29.5 x 47.2 x 88.9" (750 x 1200 x 2258 mm)
Static load	1363.64 kg
Dynamic load	1022.73 kg
