-40 - 75C, x8 RJ-45, 10/100Mbps, 30 x 140 x 95mm, IP30, 10 - 24VAC, 5.1W
enclosure, making it suitable for installation in narrow areas. The IP30-rated enclosure ensures protection against dusty industrial environments. The ESW108-A is also compliant
with C1D2, making it perfect for harsh environments.
Advantech
Advantech BB-ESW108-A Unmanaged Fast Ethernet (10/100) Black
Part number:
ESW108-A
$156.92
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Supports 10/100 Mbps auto negotiation
- Compact size with DIN rail and wall mount
- Supports redundant 12~48 VDC or 10~24 VAC power input
- Wide operating temperature range of -40 ~ 75°C
- C1D2 for hazardous locations
Description
The ESW108-A provides a fast Ethernet solution. Power is delivered via either +12 ~ 48 VDC or 10~24VAC redundant input design. The ESW108-A comes with a compact metalenclosure, making it suitable for installation in narrow areas. The IP30-rated enclosure ensures protection against dusty industrial environments. The ESW108-A is also compliant
with C1D2, making it perfect for harsh environments.
Specifications
| Performance | |
|---|---|
| Stackable | No |
| Technical details | |
| Product colour | Black |
| Stackable | No |
| Rack mounting | No |
| Sustainability compliance | Yes |
| Warranty period | 5 year(s) |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Power over Ethernet (PoE) | |
| Power protection features | Overload, Reverse polarity |
| Power over Ethernet (PoE) | No |
| Management features | |
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Network | |
| 10G support | No |
| Optical fiber | |
| Transmission distance (max) | 0.1 km |
| Design | |
| Wall mountable | No |
| International Protection (IP) code | IP30 |
| Product colour | Black |
| Stackable | No |
| Rack mounting | No |
| Power | |
| Power protection features | Overload, Reverse polarity |
| Power consumption (typical) | 5.1 W |
| DC input voltage | 12 - 48 V |
| Power source | AC |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating temperature (T-T) | -40 - 75 °C |
| Weight & dimensions | |
| Width | 1.18" (30 mm) |
| Depth | 5.51" (140 mm) |
| Height | 3.74" (95 mm) |
| Sustainability | |
| Sustainability compliance | Yes |
