2.7W, 12 - 48V, 802.3IEEE, 100Mbps, RJ-45, SC Fiber, 30 x 140 x 95mm
thus eliminating the need to use crossover wires. Furthermore, they can operate normally at temperatures of -10 ~ 60°C and they accept a wide voltage range of 12 ~ 48 VDC. They
also feature 3,000 VDC surge protection (EFT) against overvoltage, making them highly suitable for harsh operating environments. The EKI-2541M/2541S are enhanced Ethernet
to fiber-optic converters. Aside from their standard features, these versatile converters also feature link fault pass-through. Typically, when one side of the link fails, the other side
continues transmitting packets and waiting for a response that never arrives from the disconnected side. However, the EKI-2541M/2541S will force the link to shut down as soon as
the link failure is detected, thus giving the application software a chance to correct the problem
Advantech
Advantech EKI-2541SI network media converter 100 Mbit/s 1310 nm Single-mode Black
Part number:
EKI-2541SI-AE
$355.76
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Supports full/half duplex flow control
- Supports store and forward transmission
- Supports auto-negotiation
- Supports MDI/MDI-X auto crossover
- Supports redundant 12-48 VDC power input
- Provides flexible mounting: DIN-rail and Panel mount
- Supports wide operating temperatures from -40 to 75°C
Description
The EKI-2541M/2541S are designed to transparently convert Ethernet networks to fiber networks. The advantages of fiber optics are the wide bandwidth, EMI immunity, and longdistance transmission. Therefore, the EKI-2541M/2541S are ideal for fiber-to-building applications at central offices or local sites. These converters support MDI/MDIX auto detection,thus eliminating the need to use crossover wires. Furthermore, they can operate normally at temperatures of -10 ~ 60°C and they accept a wide voltage range of 12 ~ 48 VDC. They
also feature 3,000 VDC surge protection (EFT) against overvoltage, making them highly suitable for harsh operating environments. The EKI-2541M/2541S are enhanced Ethernet
to fiber-optic converters. Aside from their standard features, these versatile converters also feature link fault pass-through. Typically, when one side of the link fails, the other side
continues transmitting packets and waiting for a response that never arrives from the disconnected side. However, the EKI-2541M/2541S will force the link to shut down as soon as
the link failure is detected, thus giving the application software a chance to correct the problem
Specifications
| Network | |
|---|---|
| Fiber optic connector | SC |
| Data transfer rate | 100 Mbit/s |
| Converter input interface | 10Base-T, 100BASE-FX, 100Base-TX |
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Maximum data transfer rate | 100 Mbit/s |
| Technical details | |
| Wavelength | 1310 nm |
| Maximum transfer distance | 3937" (100 m) |
| Fiber mode structure | Single-mode |
| Tx power (min) | -14 dBmW |
| Tx power (max) | 20 dBmW |
| Rx power (min) | -34 dBmW |
| Rx power (max) | -31 dBmW |
| Data transfer rate | 100 Mbit/s |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SC |
| Performance | |
| Wavelength | 1310 nm |
| Maximum transfer distance | 3937" (100 m) |
| Fiber mode structure | Single-mode |
| Tx power (min) | -14 dBmW |
| Tx power (max) | 20 dBmW |
| Rx power (min) | -34 dBmW |
| Rx power (max) | -31 dBmW |
| Mean time between failures (MTBF) | 577175 h |
| Design | |
| Product colour | Black |
| Endurance | |
| Mean time between failures (MTBF) | 577175 h |
| Power | |
| Input voltage | 12 - 48 V |
| Power consumption (typical) | 2.7 W |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Width | 1.18" (30 mm) |
| Depth | 5.51" (140 mm) |
| Height | 3.74" (95 mm) |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 60 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
