DuraSled DS820 - 1D/2D Linear Barcode Plus QR Code Scanner, iPhone, iPod
Certified by Apple® for iOS devices (iPad®, iPhone®, iPod Touch® devices).
SOCKET MOBILE
Socket Mobile DS820 Handheld bar code reader 1D/2D Linear Black
Part number:
CX4014-3077
$294.03
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Bluetooth Wireless Technology - Connects easily to iPhone or iPod Bluetooth devices
- Compatibility - Socket Mobile's SDK is integrated in over 700+ applications, and our scanners are one of the most natively integrated scanners available. (Supports HID keyboard emulation to work with any application.)
- Scanning – 2D & 1D omni-directional barcode scanning with visible and safe aimer
- Scanner Feedback – Scanner provides audible scan tones, hand pulsation and Bluetooth indicator
- Long-Lasting Replaceable Battery - Power to last a full workday
- One-Handed Operation – Insert the iPhone/iPod for a one-handed scanning solution
- Interchangeable Scanner - Barcode scanner can be used separately, attached to a different iPhone/iPod, or inserted into any model DuraSled (case only)
- Interchangeable Accessories – All accessories for all DuraSleds models are the same
- Protective material - Elastomeric (rubber) case protects both the Apple device and scanner
- Battery Charging - Integrates connectors from scanner & Apple device for dual charging. Features magnetic contacts for ease of docking
Description
The DuraSled™ DS820 is a linear barcode & QR Code reader sled for 1D/2D barcodes, with Bluetooth® wireless technology for Apple iPhones and iPods. The DuraSled reads printed or on-screen barcodes. It is easy-to-use and ideal for delivery services, asset tracking, ticketing, and other application-driven mobile solutions. Its case protects phones from drop damage and provides simultaneous charging of the scanner and the phone.Certified by Apple® for iOS devices (iPad®, iPhone®, iPod Touch® devices).
Specifications
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR Code |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, Interleaved 2 of 5, MSI, Matrix 2 of 5, UPC-A |
| Working distance | 15" (38 cm) |
| Sensor type | Linear |
| Scanner type | 1D/2D |
| Light levels (direct sunlight) | 0 - 100000 lx |
| Ports & interfaces | |
| Connectivity technology | Wireless |
| Wireless range | 393.7" (10 m) |
| Bluetooth version | 2.1+EDR |
| Standard interfaces | Bluetooth |
| Performance | |
| LED indicators | Battery level, Bluetooth |
| International Protection (IP) code | IP40 |
| Product colour | Black |
| Certification | FCC Part 15 Class C, RSS 210, iCES 003, C-Tick, CISPR 22, CE EN55022, EN55024, TELEC |
| Country of origin | China |
| Ambient lighting | Yes |
| Light levels (direct sunlight) | 0 - 100000 lx |
| Design | |
| Type | Handheld bar code reader |
| LED indicators | Battery level, Bluetooth |
| International Protection (IP) code | IP40 |
| Product colour | Black |
| Certification | FCC Part 15 Class C, RSS 210, iCES 003, C-Tick, CISPR 22, CE EN55022, EN55024, TELEC |
| Power | |
| Power source type | Battery |
| Number of batteries supported | 1 |
| Charging time | 8 h |
| Battery life | 25 h |
| Battery voltage | 3.7 V |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery capacity | 700 mAh |
| Weight & dimensions | |
| Width | 0.291" (7.4 mm) |
| Depth | 5.78" (146.7 mm) |
| Height | 2.81" (71.5 mm) |
| Weight | 4 oz (113.5 g) |
| Technical details | |
| Type | Handheld bar code reader |
| LED indicators | Battery level, Bluetooth |
| International Protection (IP) code | IP40 |
| Product colour | Black |
| Certification | FCC Part 15 Class C, RSS 210, iCES 003, C-Tick, CISPR 22, CE EN55022, EN55024, TELEC |
| Sustainability compliance | Yes |
| Warranty period | 1 year(s) |
| Compliance certificates | RoHS |
| Packaging data | |
| Charging base | No |
| Operational conditions | |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Light levels (direct sunlight) | 0 - 100000 lx |
| Packaging content | |
| Charging base | No |
