1000Mhz, 9 - 36V, IP30, 31.2 x 94 x 129mm, 512 MB, 4096Mb, RJ45, 2 x Ethernet, RS232, RS485, LED, IP30, 2x R-SMA, 2x2 MIMO
network. Industrial M2M and IoT applications include SCADA, industrial PCs, HMIs, traffic
controllers, CCTV, meters, kiosks, UPS systems, and much more.
With LTE Cat.4 upload speeds of up to 50 Mbps and download speeds of up to 150 Mbps,
the router provides ample bandwidth for high data demand applications. The device has two
SIM card readers for carrier failover redundancy. As an addition the router is ready to use
internal eSIM (Customization).
In addition to its two independent Ethernet ports, serial ports RS232 and RS485, ICR3200 has built-in digital I/O connectivity, backup real-time clock and sleep mode support.
An optional built-in modules WiFi with 802.11a,b,g,n,ac modes, 2×2 MIMO support and
Bluetooth v5.1 are available. Optional built-in GNSS chipset provides information about the
accurate position of the router.
The ICR-3200 places intelligence at the network edge with a powerful Cortex A8 CPU at
1GHz, 512 MB RAM, and 4 GB EMMC FLASH memory in pSLC mode for a long-lifetime
and critical industrial applications. 1.3 GB of memory space is allocated for customer SW
applications and data.
With an open Linux-based ICR-OS operating system and wide possibilities
of programming customer SW applications in Python, C/C++ or browser-based
flow editor Node-RED, or even Docker containers the ICR-3200 offers a real open
development platform for Industrial IoT applications.
The Advantech existing Router App library (User modules) with apps already developed
to enhance specific router functionality including industrial protocol conversions and
support of IoT platforms such as MS Azure, Cumulocity, and others are supported
on the router.
The router supports VPN tunnel creation using various protocols to ensure safe
communications. The router provides diagnostic functions which include automatic
monitoring of the wireless and wired connections, automatic restart in case
of connection losses, and a hardware watchdog that monitors the router status.
ICR-3200 is easy to manage using WebAccess/DMP, full-featured cloud-based
management, provisioning, and monitoring tool for mass deployment.
The WebAccess/VPN is a perfect way how to create secure virtual private networks
on the Internet.
Advantech
Advantech ICR-3241W wired router Fast Ethernet Black
Part number:
ICR-3241W
$583.47
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Wi-Fi 802.11ac using MU-MIMO technology
- GNSS receiver
- Robust metal cover with DIN and Wall mount options
- Operational temperature range from -40 °C to +75 °C
- Sleep mode & Power ignition & Backup real time clock
- Advanced networking, Diagnostics, VPN support, Firewall
Description
The ICR-3200 4G LTE gateway is the perfect way to connect IP or serial devices via a cellularnetwork. Industrial M2M and IoT applications include SCADA, industrial PCs, HMIs, traffic
controllers, CCTV, meters, kiosks, UPS systems, and much more.
With LTE Cat.4 upload speeds of up to 50 Mbps and download speeds of up to 150 Mbps,
the router provides ample bandwidth for high data demand applications. The device has two
SIM card readers for carrier failover redundancy. As an addition the router is ready to use
internal eSIM (Customization).
In addition to its two independent Ethernet ports, serial ports RS232 and RS485, ICR3200 has built-in digital I/O connectivity, backup real-time clock and sleep mode support.
An optional built-in modules WiFi with 802.11a,b,g,n,ac modes, 2×2 MIMO support and
Bluetooth v5.1 are available. Optional built-in GNSS chipset provides information about the
accurate position of the router.
The ICR-3200 places intelligence at the network edge with a powerful Cortex A8 CPU at
1GHz, 512 MB RAM, and 4 GB EMMC FLASH memory in pSLC mode for a long-lifetime
and critical industrial applications. 1.3 GB of memory space is allocated for customer SW
applications and data.
With an open Linux-based ICR-OS operating system and wide possibilities
of programming customer SW applications in Python, C/C++ or browser-based
flow editor Node-RED, or even Docker containers the ICR-3200 offers a real open
development platform for Industrial IoT applications.
The Advantech existing Router App library (User modules) with apps already developed
to enhance specific router functionality including industrial protocol conversions and
support of IoT platforms such as MS Azure, Cumulocity, and others are supported
on the router.
The router supports VPN tunnel creation using various protocols to ensure safe
communications. The router provides diagnostic functions which include automatic
monitoring of the wireless and wired connections, automatic restart in case
of connection losses, and a hardware watchdog that monitors the router status.
ICR-3200 is easy to manage using WebAccess/DMP, full-featured cloud-based
management, provisioning, and monitoring tool for mass deployment.
The WebAccess/VPN is a perfect way how to create secure virtual private networks
on the Internet.
Specifications
| Ethernet LAN features | |
|---|---|
| Ethernet LAN data rates | 10,100 Mbit/s |
| Cabling technology | 10/100Base-T(X) |
| Network | |
| Network address translation (NAT) | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Cabling technology | 10/100Base-T(X) |
| Ethernet interface type | Fast Ethernet |
| Memory | |
| Internal memory | 512 MB |
| Performance | |
| Storage media | eMMC |
| Internal storage capacity | 4.1 TB |
| Internal memory | 512 MB |
| Built-in processor | Yes |
| Processor frequency | 1000 MHz |
| WAN connection | |
| Ethernet WAN | Yes |
| SIM card slot | Yes |
| Mobile network | |
| Mobile network generation | 3G |
| Management features | |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces | |
| Fast Ethernet (copper) ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 ports | 1 |
| Protocols | |
| DHCP server | Yes |
| DHCP client | Yes |
| Technical details | |
| Built-in processor | Yes |
| Processor frequency | 1000 MHz |
| LED indicators | Yes |
| Product colour | Black |
| Sustainability compliance | Yes |
| Compliance certificates | Federal Communications Commission (FCC), RoHS |
| Security | |
| IP address filtering | Yes |
| Network address translation (NAT) | Yes |
| Firewall | Yes |
| Security algorithms | 3DES, AES, SSH, WEP, WPA, WPA2, WPA3 |
| System event log | Yes |
| MAC address filtering | Yes |
| Access Control List (ACL) | Yes |
| Features | |
| Storage media | eMMC |
| Internal storage capacity | 4.1 TB |
| Internal memory | 512 MB |
| Built-in processor | Yes |
| Processor frequency | 1000 MHz |
| Design | |
| Housing material | Metal |
| LED indicators | Yes |
| Product colour | Black |
| Power | |
| Power source type | DC |
| Output voltage | 9 - 36 V |
| Power consumption (typical) | 4 W |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 1.23" (31.2 mm) |
| Depth | 3.7" (94 mm) |
| Height | 5.08" (129 mm) |
