4 GB DRAM, 4096 VLAN, 24 10/100/1000 Ethernet PoE+, 2x10G Uplink, 640WAC, 1 RU, LAN Base set

Description

The Cisco® Catalyst® 3650 Series is the next generation of enterprise-class standalone and stackable access-layer switches that provide the foundation for full convergence between wired and wireless on a single platform. The 3650 Series is built on the advanced Cisco StackWise®-160, and takes advantage of the new Cisco Unified Access™ Data Plane (UADP) application-specific integrated circuit (ASIC). This switch can enable uniform wired-wireless policy enforcement, application visibility, flexibility, application optimization, and superior resiliency. The 3650 Series switches support full IEEE 802.3at Power over Ethernet P.lus (PoE+), Cisco Universal Power over Ethernet (Cisco UPOE®) on the Cisco Catalyst 3650 Series multigigabit switches, and offer modular and field-replaceable redundant fans and power supplies. The 3650 Series switches also come in a 12-inch lower depth form factor so that you can deploy them in tight wiring closets in remote branches and offices where depth of the switch is a concern. In addition, the 3650 multigigabit switches support current and next-generation wireless speeds and standards (including 802.11ac Wave 2) on existing cabling infrastructure. The 3650 Series switches help increase wireless productivity and reduce TCO.

Specifications

Management features
Multicast support	Yes
Traffic shaping	Yes
Traffic classification	Yes
ARP inspection	Yes
Switch type	Managed
Web-based management	Yes
Quality of Service (QoS) support	Yes
MIB support	Yes
Switch layer	L2
Network
IGMP snooping	Yes
Cable types supported	Cat5, Cat5e, Cat6, Cat6a
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3x, IEEE 802.3z
Full duplex	Yes
VLAN support	Yes
Spanning tree protocol	Yes
Rate limiting	Yes
Link aggregation	Yes
IP routing	Yes
Flow control support	Yes
Auto MDI/MDI-X	Yes
10G support	Yes
Virtual LAN features	Stacked VLAN, Private VLAN, Port-based VLAN
Virtual LAN features
VLAN support	Yes
Virtual LAN features	Stacked VLAN, Private VLAN, Port-based VLAN
Data transmission
Multicast MAC address table	24000 entries
Jumbo frames	9198
MAC address table	32000 entries
Switching capacity	256 Gbit/s
Jumbo frames support	Yes
Optical fiber
Fiber optic connector	SFP+
Performance
Stackable	Yes
Mean time between failures (MTBF)	304860 h
Flash memory	4096 MB
Power
Power connector	DC-in jack
Power consumption (max)	975 W
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	5 - 12 A
Technical details
Form factor	1U
Product colour	Black
Stackable	Yes
Mean time between failures (MTBF)	304860 h
Rack mounting	Yes
Ports & interfaces
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Fiber optic connector	SFP+
Power connector	DC-in jack
Security
BPDU filtering/protection	Yes
SSH/SSL support	Yes
MAC address filtering	Yes
IGMP snooping	Yes
Access Control List (ACL)	Yes
DHCP features	DHCP server, DHCP client
Multicast features
Multicast MAC address table	24000 entries
Multicast support	Yes
Memory
Flash memory	4096 MB
Design
Wall mountable	Yes
Form factor	1U
Product colour	Black
Stackable	Yes
LED indicators	Yes
Rack mounting	Yes
Indication
LED indicators	Yes
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity	24
Total Power over Ethernet (PoE) budget	390 W
Power over Ethernet (PoE)	Yes
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-5 - 45 °C
Operating altitude	0 - 118110.2" (0 - 3000 m)
Weight & dimensions
Width	17.5" (445 mm)
Depth	11.7" (296 mm)
Height	1.73" (44 mm)
Weight	12.3 lbs (5.56 kg)
Packaging data
AC adapter included	Yes
Packaging content
AC adapter included	Yes
