LCD panel, 120V, 8x 5-15R, 1x USB, Black

Description

Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.

Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance.

Power-saving outlets
Automatically cuts power to idle equipment to conserve electricity.

Resettable circuit breaker
Easy recovery from overloads; no need to replace a fuse.

LCD display
Alpha-Numeric Display which displays system parameters and alarms.

Data-line Protection
Protection of data lines (Ethernet, Coaxial and Phone lines) ensures complete protection of your equipment from surges. It is very important to protect your equipment from “back door” surges traveling through data lines, as they can be as damaging to your equipment as surges traveling over power lines.

Battery-protected and surge-only outlets
Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment.

Cold-start capable
Provides temporary battery power when the utility power is out.

Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced.

Disconnected battery notification
Warns when a battery is not available to provide backup power.

Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Adjustable voltage-transfer points
Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.

Adjustable voltage sensitivity
Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.

Audible alarms
Provides notification of changing utility power and UPS conditions.

Transformer-block spaced outlets
Protect equipment with input transformer blocks without blocking access to other receptacles.

Boost and Trim Automatic Voltage Regulation (AVR)
Gives higher application availability by correcting low and high voltage conditions without using the battery.

Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Building Wiring Fault Indicator
This LED informs users of potentially dangerous wiring problems in the wall circuit.

Battery replacement without tools
Allows quick, easy battery replacement.

Boost and Trim Automatic Voltage Regulation (AVR)
Eliminates voltage fluctuations as a source of AV signal degradation and component power-supply stress.

Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.

Isolated filter banks
Eliminates electromagnetic and radio frequency interference (EMI/RFI) as a source of audio-video signal degradation.

Dataline Surge Protection
Provides protection of connected equipment from power surges on the data lines.

Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Resettable circuit breakers
Enables a quick recovery from overload events.

Multiple mounting methods
Allows for standardization on one product for use in different environments.

Front-access servicing
Simplifies installation and maintenance while minimizing space requirements.

Adjustable voltage sensitivity
Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.

Sequenced turn on/off
Helps power on components in the proper order to prevent speaker stress. Proper sequencing can also help manage current draw on startup to prevent unnecessary circuit breaker tripping.

LED & display dimmer
Adjust the unit's LED and display brightness independently of each other to suit your individual tastes and environment.

Specifications

Power
Output power	865 W
Output operation voltage (max)	120 V
Output power capacity	1.5 kVA
Input frequency	50/60 Hz
Battery
Battery type	Lead-Acid
Number of battery cells	1
Battery recharge time	16 h
Performance
LED indicators	Yes
EMI/RFI noise filtering	Yes
EMI/RFI noise filtering	45 dB
Surge protection features	Coax, Network, Telephone
Features
Output power	865 W
Output operation voltage (max)	120 V
EMI/RFI noise filtering	Yes
EMI/RFI noise filtering	45 dB
Surge protection features	Coax, Network, Telephone
Output power capacity	1.5 kVA
Input frequency	50/60 Hz
Ports & interfaces
AC outlets quantity	8 AC outlet(s)
AC outlet types	NEMA 5–15R
Power plug	C14 coupler
USB 2.0 ports quantity	1
Modem (RJ-11) ports	2
Design
Form factor	Rackmount
LED indicators	Yes
Product colour	Black
Certification	FCC 15 B, UL 1778
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 40 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Non-operating altitude	0 - 118110.2" (0 - 3000 m)
Technical details
Compliance certificates	RoHS
Packaging data
Package dimensions (WxDxH)	22 x 21.2 x 8.07" (558 x 539 x 205 mm)
Package weight	35.3 lbs (16 kg)
Certificates
Certification	FCC 15 B, UL 1778
Compliance certificates	RoHS
Weight & dimensions
Weight	30.9 lbs (14 kg)
Width	17" (431 mm)
Package weight	35.3 lbs (16 kg)
Height	3.82" (97 mm)
Depth	16" (406 mm)
Other features
Battery type	Lead-Acid
Input connection type	C14
Package dimensions (WxDxH)	22 x 21.2 x 8.07" (558 x 539 x 205 mm)
Operating temperature (T-T)	32 - 104 °F
Nominal output voltage	120 V
Nominal input voltage	120 V
