Intel Core i7-1370P, Intel® Core™ i7, BGA 1744, Tray, Intel, i7-1370P, 64-bit
Intel
Intel Core i7-1370P processor 24 MB Smart Cache Tray
Part number:
FJ8071505204501
$470.17
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Description
Intel Core i7-1370P. Processor family: Intel® Core™ i7, Processor socket: BGA 1744, Package type: Tray. Memory channels: Dual-channel, Maximum internal memory supported by processor: 64 GB, Memory types supported by processor: LPDDR5x-SDRAM, DDR4-SDRAM, DDR5-SDRAM, LPDDR4x-SDRAM, LPDDR5-SDRAM. On-board graphics card model: Intel Iris Xe Graphics, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card dynamic frequency (max): 1500 MHz. Market segment: Mobile, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0, Export Control Classification Number (ECCN): 5A992C. Intel® Turbo Boost Max Technology 3.0 frequency: 5.2 GHz, Chipset / PCH PCIe Revision: Gen 3, Microprocessor PCIe Revision: Gen 4Specifications
| Processor | |
|---|---|
| Processor generation | 13th gen Intel® Core™ i7 |
| Processor manufacturer | Intel |
| Processor codename | Raptor Lake |
| Configurable TDP-down | 20 W |
| Processor cache | 24 MB |
| Processor ARK ID | 232146 |
| Processor model | i7-1370P |
| Processor threads | 20 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 5.2 GHz |
| Stepping | J0 |
| Processor family | Intel® Core™ i7 |
| Processor cores | 14 |
| Processor socket | BGA 1744 |
| Processor cache type | Smart Cache |
| Package type | Tray |
| Performance cores | 6 |
| Efficient cores | 8 |
| Performance-core boost frequency | 5.2 GHz |
| Efficient-core boost frequency | 3.9 GHz |
| Processor base power | 28 W |
| Maximum turbo power | 64 W |
| Minimum Assured Power | 20 W |
| Memory | |
| Maximum internal memory supported by processor | 64 GB |
| Memory types supported by processor | LPDDR5x-SDRAM, DDR4-SDRAM, DDR5-SDRAM, LPDDR4x-SDRAM, LPDDR5-SDRAM |
| Memory channels | Dual-channel |
| ECC | No |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
| Number of execution units | 96 |
| On-board graphics card ID | 0xA7A0 |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120 Hz |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics card DirectX version | 12.1 |
| On-board graphics card OpenGL version | 4.6 |
| On-board graphics card model | Intel Iris Xe Graphics |
| On-board graphics card | Yes |
| On-board graphics card dynamic frequency (max) | 1500 MHz |
| Discrete graphics card model | Not available |
| Multi-Format Codec Engines | 2 |
| Power | |
| Configurable TDP-down | 20 W |
| Technical details | |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel® Active Management Technology (Intel® AMT) | Yes |
| Intel® Secure Key | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Flex Memory Access | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Execute Disable Bit | Yes |
| PCI Express slots version | 4.0 |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Status | Launched |
| Market segment | Mobile |
| Launch date | Q1'23 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor cache type | Smart Cache |
| OpenCL version | 3.0 |
| Features | |
| On-board graphics card ID | 0xA7A0 |
| Maximum number of PCI Express lanes | 20 |
| Processor package size | 50 x 25 mm |
| Processor ARK ID | 232146 |
| Thermal Monitoring Technologies | Yes |
| Execute Disable Bit | Yes |
| PCI Express slots version | 4.0 |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Market segment | Mobile |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Processor special features | |
| Intel® Smart Sound Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Turbo Boost Max Technology 3.0 | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® OS Guard | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel® Active Management Technology (Intel® AMT) | Yes |
| Intel® Secure Key | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Flex Memory Access | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® Boot Guard | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Image Processing Unit | 6.0 |
| Intel® Adaptix Technology | Yes |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.2 GHz |
| Intel® Total Memory Encryption | Yes |
| Intel® Thunderbolt 4 | Yes |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Wake on Voice | Yes |
| Intel® Thread Director | Yes |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Yes |
| MIPI SoundWire | 1.2 |
| Intel® Total Memory Encryption - Multi Key | Yes |
| Intel® Threat Detection Technology (TDT) | Yes |
| Intel® QuickAssist Software Acceleration | Yes |
| Intel® Hardware Shield Eligibility | Yes |
| Intel vPro® Enterprise Platform Eligibility | Yes |
| Intel® Standard Manageability (ISM) | Yes |
| Intel® Stable IT Platform Program (SIPP) | Yes |
| Intel® One-Click Recovery | Yes |
| Microprocessor PCIe Revision | Gen 4 |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) | Yes |
| Intel® Remote Platform Erase (RPE) | Yes |
| Chipset / PCH PCIe Revision | Gen 3 |
| Operational conditions | |
| Tjunction | 100 °C |
| Packaging data | |
| Package type | Tray |
| Logistics data | |
| Harmonized System (HS) code | 8542310001 |
| Weight & dimensions | |
| Processor package size | 50 x 25 mm |
| Other features | |
| Maximum internal memory | 64 GB |
| CPU configuration (max) | 1 |
| Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
