Intel Atom E3845, Intel Atom®, BGA 1170, 22 nm, Tray, Intel, E3845
Intel
Intel Atom E3845 processor 1.91 GHz 2 MB L2 Tray
Part number:
FH8065301487717
$60.60
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Description
Intel Atom E3845. Processor family: Intel Atom®, Processor socket: BGA 1170, Processor lithography: 22 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 8 GB, Memory types supported by processor: DDR3L-SDRAM. On-board graphics card model: Intel® HD Graphics, On-board graphics card base frequency: 542 MHz, On-board graphics card burst frequency: 792 MHz. Market segment: Embedded, PCI Express configurations: 1x1, 1x4, 2x1, Graphics & IMC lithography: 22 nm. USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)Specifications
| Processor | |
|---|---|
| Processor base frequency | 1.91 GHz |
| Processor manufacturer | Intel |
| Cooler included | No |
| Processor codename | Bay Trail |
| Thermal Design Power (TDP) | 10 W |
| Processor cache | 2 MB |
| Processor ARK ID | 78475 |
| Processor model | E3845 |
| Processor threads | 4 |
| Processor operating modes | 64-bit |
| Stepping | B3 |
| FSB Parity | No |
| Component for | Netbook/nettop |
| Processor lithography | 22 nm |
| Processor family | Intel Atom® |
| Processor cores | 4 |
| Processor socket | BGA 1170 |
| Processor code | SR1RE |
| Processor series | Intel Atom E3800 Series |
| Processor cache type | L2 |
| Memory | |
| Maximum internal memory supported by processor | 8 GB |
| Memory types supported by processor | DDR3L-SDRAM |
| Memory clock speeds supported by processor | 1333 MHz |
| Supported memory types | DDR3L-SDRAM |
| Memory channels | Dual-channel |
| ECC | Yes |
| Graphics | |
| On-board graphics card burst frequency | 792 MHz |
| Number of displays supported (on-board graphics) | 2 |
| On-board graphics card model | Intel® HD Graphics |
| On-board graphics card | Yes |
| On-board graphics card base frequency | 542 MHz |
| Power | |
| Thermal Design Power (TDP) | 10 W |
| Technical details | |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel Rapid Storage Technology | No |
| Thermal Monitoring Technologies | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Intel® Turbo Boost Technology | No |
| Intel Trusted Execution Technology | No |
| Intel® Quick Sync Video Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel Flex Memory Access | No |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Dual Display Capable Technology | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Execute Disable Bit | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 1x1, 1x4, 2x1 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Enhanced Halt State | No |
| Intel Demand Based Switching | No |
| Graphics & IMC lithography | 22 nm |
| Embedded options available | Yes |
| CPU configuration (max) | 1 |
| Processor code | SR1RE |
| Product type | System on Chip |
| Processor cache | 2048 KB |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel 64 | Yes |
| Video decoding | Yes |
| Thermal Design Power (TDP) | 10 W |
| Supported memory types | DDR3L-SDRAM |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Status | Launched |
| Processor series | Intel Atom E3800 Series |
| Market segment | Embedded |
| Launch date | Q4'13 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor cache type | L2 |
| Maximum memory | 8 GB |
| Processor brand name | Intel Atom |
| Last change | 63903513 |
| Product family | Intel Atom Processor |
| Features | |
| Maximum number of PCI Express lanes | 4 |
| Thermal Design Power (TDP) | 10 W |
| Processor package size | 25mm x 27mm |
| Processor ARK ID | 78475 |
| Thermal Monitoring Technologies | No |
| Execute Disable Bit | Yes |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 1x1, 1x4, 2x1 |
| Graphics & IMC lithography | 22 nm |
| Embedded options available | Yes |
| CPU configuration (max) | 1 |
| Processor code | SR1RE |
| Market segment | Embedded |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Commodity Classification Automated Tracking System (CCATS) | G143235 |
| PCI Express CEM revision | 2.0 |
| I/O configuration | |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| Integrated LAN | No |
| Total number of SATA connectors | 2 |
| Processor special features | |
| Intel Clear Video Technology | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel 64 | Yes |
| Conflict-Free processor | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel Rapid Storage Technology | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Intel® Turbo Boost Technology | No |
| Intel Trusted Execution Technology | No |
| Intel® Quick Sync Video Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel Flex Memory Access | No |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Dual Display Capable Technology | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Enhanced Halt State | No |
| Intel Demand Based Switching | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® vPro™ Platform Eligibility | No |
| Operational conditions | |
| Tjunction | 110 °C |
| Packaging data | |
| Package type | Tray |
| Logistics data | |
| Harmonized System (HS) code | 8542310001 |
| Weight & dimensions | |
| Processor package size | 25mm x 27mm |
| Other features | |
| Video decoding | Yes |
| Maximum internal memory | 8 GB |
| Maximum internal memory | 8192 MB |
| CPU configuration (max) | 1 |
| Processor code | SR1RE |
