Intel Atom P5332, Intel Atom®, BGA 2106, 10 nm, Intel, P5332, 2.2 GHz
Intel
Intel Atom P5332 processor 2.2 GHz 13.5 MB
Part number:
NN8069204099603
$481.66
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Description
Intel Atom P5332. Processor family: Intel Atom®, Processor socket: BGA 2106, Processor lithography: 10 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 256 GB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, Use conditions: Communications Extended Temp, Supported instruction sets: SSE4.2. USB version: 2.0/3.2 Gen 1 (3.1 Gen 1). Chipset / PCH PCIe Revision: Gen 3Specifications
| Processor | |
|---|---|
| Processor base frequency | 2.2 GHz |
| Processor manufacturer | Intel |
| Thermal Design Power (TDP) | 61 W |
| Processor cache | 13.5 MB |
| Processor ARK ID | 134796 |
| Processor model | P5332 |
| Processor threads | 12 |
| Processor operating modes | 64-bit |
| Stepping | C0 |
| Number of QPI links | 0 |
| Processor lithography | 10 nm |
| Processor family | Intel Atom® |
| Processor cores | 12 |
| Box | No |
| Processor socket | BGA 2106 |
| Efficient cores | 12 |
| Memory | |
| Maximum internal memory supported by processor | 256 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Dual-channel |
| ECC | Yes |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card model | Not available |
| Power | |
| Thermal Design Power (TDP) | 61 W |
| Technical details | |
| Intel® Secure Key | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| PCI Express slots version | 3.0 |
| Supported instruction sets | SSE4.2 |
| Scalability | 1S |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Thermal Design Power (TDP) | 61 W |
| Supported memory types | DDR4-SDRAM |
| Status | Launched |
| Market segment | Server |
| Launch date | Q2'22 |
| Intel Virtualization Technology (VT-x) | Yes |
| Number of UPI links | 0 |
| Memory speed (max) | 2400 MHz |
| Number of UARTs | 3 |
| Features | |
| Maximum number of PCI Express lanes | 32 |
| Thermal Design Power (TDP) | 61 W |
| Processor package size | 47.5 x 47.5 mm |
| Processor ARK ID | 134796 |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| PCI Express slots version | 3.0 |
| Supported instruction sets | SSE4.2 |
| Scalability | 1S |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Market segment | Server |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A002R |
| Commodity Classification Automated Tracking System (CCATS) | G175230 |
| Use conditions | Communications Extended Temp |
| I/O configuration | |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity | 8 |
| Integrated LAN | Yes |
| Total number of SATA connectors | 16 |
| General Purpose IO | Yes |
| Processor special features | |
| Intel Software Guard Extensions (Intel SGX) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| General Purpose IO | Yes |
| Intel QuickAssist Technology | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel® Secure Key | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® Boot Guard | Yes |
| Intel® Thermal Velocity Boost | No |
| Intel® Volume Management Device (VMD) | No |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Chipset / PCH PCIe Revision | Gen 3 |
| Packaging data | |
| Package type | Tray |
| Logistics data | |
| Harmonized System (HS) code | 8542310001 |
| Weight & dimensions | |
| Processor package size | 47.5 x 47.5 mm |
| Other features | |
| Maximum internal memory | 256 GB |
| CPU configuration (max) | 1 |
