Intel Core i7-6600U, Intel® Core™ i7, BGA 1356, 14 nm, Tray, Intel, i7-6600U
Intel
Intel Core i7-6600U processor 2.6 GHz 4 MB Smart Cache Tray
Part number:
FJ8066201924950
$427.53
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Description
Intel Core i7-6600U. Processor family: Intel® Core™ i7, Processor socket: BGA 1356, Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 32 GB, Memory types supported by processor: DDR4-SDRAM, LPDDR3-SDRAM, DDR3L-SDRAM. On-board graphics card model: Intel® HD Graphics 520, Maximum on-board graphics card memory: 32 GB, On-board graphics card outputs supported: Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI. Market segment: Mobile, Use conditions: Industrial Commercial Temp, PC/Client/Tablet, PCI Express configurations: 1x4, 2x2, 1x2+2x1, 4x1. Intel® Turbo Boost Technology 2.0 frequency: 3.4 GHzSpecifications
| Processor | |
|---|---|
| Processor generation | 6th gen Intel® Core™ i7 |
| Processor base frequency | 2.6 GHz |
| Processor manufacturer | Intel |
| Cooler included | No |
| Processor codename | Skylake |
| Configurable TDP-down | 7.5 W |
| Memory bandwidth supported by processor (max) | 34.1 GB/s |
| Thermal Design Power (TDP) | 15 W |
| Processor cache | 4 MB |
| Processor ARK ID | 88192 |
| Processor model | i7-6600U |
| Processor threads | 4 |
| System bus rate | 4 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.4 GHz |
| Stepping | D1 |
| Bus type | OPI |
| Processor lithography | 14 nm |
| Processor family | Intel® Core™ i7 |
| Processor cores | 2 |
| Processor socket | BGA 1356 |
| Processor code | SR2F1 |
| Processor series | Intel Core i7-6600 Mobile Series |
| Configurable TDP-up frequency | 2.8 GHz |
| Configurable TDP-up | 25 W |
| Configurable TDP-down frequency | 0.8 GHz |
| Processor cache type | Smart Cache |
| Generation | 6th Generation |
| Memory | |
| Maximum internal memory supported by processor | 32 GB |
| Memory types supported by processor | DDR4-SDRAM, LPDDR3-SDRAM, DDR3L-SDRAM |
| Memory clock speeds supported by processor | 1866,2133,1600 MHz |
| Memory bandwidth supported by processor (max) | 34.1 GB/s |
| Supported memory types | DDR4-SDRAM, LPDDR3-SDRAM, DDR3L-SDRAM |
| Memory channels | Dual-channel |
| ECC | No |
| Graphics | |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI |
| On-board graphics card maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics card ID | 1916 |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card 4K support | Yes |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 24 Hz |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
| Maximum graphics card memory | 1740 MB |
| Maximum on-board graphics card memory | 32 GB |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card model | Intel® HD Graphics 520 |
| On-board graphics card | Yes |
| On-board graphics card dynamic frequency (max) | 1050 MHz |
| On-board graphics card base frequency | 300 MHz |
| Maximum graphics card memory | 32 GB |
| Power | |
| Configurable TDP-down | 7.5 W |
| Thermal Design Power (TDP) | 15 W |
| Configurable TDP-down frequency | 0.8 GHz |
| Technical details | |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Cache memory | 4 MB |
| Intel TSX-NI | Yes |
| Intel® Secure Key | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Wireless Display (Intel® WiDi) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Trusted Execution Technology | Yes |
| Intel® Smart Response Technology | Yes |
| Intel Smart Connect Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Flex Memory Access | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x4, 2x2, 1x2+2x1, 4x1 |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| Supported processor frequency (max) | 3400 GHz |
| L2 cache | 4096 KB |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Enhanced Halt State | Yes |
| Graphics & IMC lithography | 14 nm |
| Embedded options available | Yes |
| CPU configuration (max) | 1 |
| Processor code | SR2F1 |
| Graphics output | eDP/DP/HDMI/DVI |
| Video compression formats | Yes |
| Product type | System on Chip |
| Processor cache | 4096 KB |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Video decoding | Yes |
| Maximum graphics card memory | 1740 MB |
| Thermal Design Power (TDP) | 15 W |
| Supported memory types | DDR4-SDRAM, LPDDR3-SDRAM, DDR3L-SDRAM |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Status | Launched |
| Product name | Intel Core i7-6600U (4M Cache, up to 3.40 GHz) |
| Processor series | Intel Core i7-6600 Mobile Series |
| OpenGL support | Yes |
| Maximum resolution & refresh rate (VGA) | N/A |
| Maximum resolution & refresh rate (Integrated Flat Panel) | 4096x2304@60Hz |
| Maximum resolution & refresh rate (HDMI) | 4096x2304@24Hz |
| Maximum resolution & refresh rate (DisplayPort) | 4096x2304@60Hz |
| Market segment | Mobile |
| Launch date | Q3'15 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Stable Image Platform Program (SIPP) version | 1.00 |
| Intel Smart Response Technology version | 1.00 |
| Intel Small Business Advantage (SBA) version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Identity Protection Technology version | 1.00 |
| Graphics max dynamic frequency | 1.05 GHz |
| Configurable TDP-up frequency | 2.8 GHz |
| Configurable TDP-up | 25 W |
| Configurable TDP-down frequency | 0.8 GHz |
| Processor cache type | Smart Cache |
| Bus type units | GT/s |
| Bus bandwidth | 4 |
| Born on date | Q3'15 |
| Maximum memory | 32 GB |
| Intel TSX-NI version | 1.00 |
| Processor brand name | Intel Core i7 Intel Core i7 Processor |
| Last change | 63903513 |
| Maximum resolution (WiDi) | 1080p |
| Product family | 6th Generation Intel Core i7 Processors |
| Maximum graphics card memory | 32 GB |
| Processor ID | 0x1916 |
| Bus speed | 4 GT/s |
| Servicing status | End of Servicing Lifetime |
| End of servicing updates date | Friday, September 30, 2022 |
| Features | |
| On-board graphics card ID | 1916 |
| Maximum number of PCI Express lanes | 12 |
| Thermal Design Power (TDP) | 15 W |
| Processor package size | 42mm x 24mm |
| Processor ARK ID | 88192 |
| Thermal Monitoring Technologies | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x4, 2x2, 1x2+2x1, 4x1 |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| Graphics & IMC lithography | 14 nm |
| Embedded options available | Yes |
| CPU configuration (max) | 1 |
| Processor code | SR2F1 |
| Market segment | Mobile |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Commodity Classification Automated Tracking System (CCATS) | G147881 |
| PCI Express CEM revision | 3.0 |
| Use conditions | Industrial Commercial Temp, PC/Client/Tablet |
| Processor special features | |
| Intel Clear Video Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Conflict-Free processor | Yes |
| Intel® Small Business Advantage (Intel® SBA) | Yes |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Intel® OS Guard | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel TSX-NI | Yes |
| Intel® Secure Key | Yes |
| Intel® Wireless Display (Intel® WiDi) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Trusted Execution Technology | Yes |
| Intel® Smart Response Technology | Yes |
| Intel Smart Connect Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Flex Memory Access | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Stable Image Platform Program (SIPP) version | 1.00 |
| Intel Smart Response Technology version | 1.00 |
| Intel Small Business Advantage (SBA) version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Identity Protection Technology version | 1.00 |
| Configurable TDP-up frequency | 2.8 GHz |
| Configurable TDP-up | 25 W |
| Intel TSX-NI version | 1.00 |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Turbo Boost Technology 2.0 frequency | 3.4 GHz |
| Intel® Transactional Synchronization Extensions | Yes |
| Operational conditions | |
| Tjunction | 100 °C |
| Packaging data | |
| Package type | Tray |
| Logistics data | |
| Harmonized System (HS) code | 8542310001 |
| Weight & dimensions | |
| Processor package size | 42mm x 24mm |
| Other features | |
| Video decoding | Yes |
| Cache memory | 4 MB |
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| Maximum internal memory | 32 GB |
| Maximum internal memory | 32768 MB |
| Supported processor frequency (max) | 3400 GHz |
| L2 cache | 4096 KB |
| CPU configuration (max) | 1 |
| Processor code | SR2F1 |
| Graphics output | eDP/DP/HDMI/DVI |
