26-Port Gigabit EdgeSmart PoE+ Switch
Trendnet
Trendnet TPE-TG262ES network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Part number:
TPE-TG262ES
Sale price
$450.19
Regular price
$459.99
Save
$9.80
2%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- 24 x Gigabit PoE+ ports
- 2 x Gigabit SFP ports (100Mbps / 1000Mbps)
- 380W PoE power budget
- Easy-to-use web-based management interface
- Supports static link aggregation, RSTP, VLAN, QoS, and IGMP Snooping
- Voice VLAN for VoIP applications
- Bandwidth control per port
- 52Gbps switching capacity
- IEEE 802.1p CoS with queue scheduling support
- Smart fans reduce noise during operation
- 1U 19” rack mountable metal housing
- NDAA / TAA compliant (U.S. and Canada only)
Description
TRENDnet’s 26-Port Gigabit EdgeSmart PoE+ Switch, model TPE-TG262ES, is a cost-effective rackmount easy smart PoE+ switch solution for high-speed gigabit PoE+ applications. This EdgeSmart switch features the most commonly used managed switch features, reducing unnecessary switch complexity. The web-based management interface offers features for traffic control, static link aggregation, RSTP, VLAN, QoS, and monitoring. TRENDnet’s TPE-TG262ES easy smart PoE+ switch provides 24 gigabit PoE+ ports for connecting network devices, such as wireless access points, IP cameras, and VoIP handsets; and two gigabit SFP ports for long-distance fiber connectivity.Specifications
| Management features | |
|---|---|
| Reset button | Yes |
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Ports & interfaces | |
| SFP module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Number of VLANs | 4094 |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| 10G support | No |
| Virtual LAN features | Private VLAN, Tagged VLAN, Voice VLAN |
| IGMP snooping | Yes |
| Data transmission | |
| Jumbo frames | 9000 |
| Packet buffer memory | 0.5 MB |
| MAC address table | 8000 entries |
| Switching capacity | 52 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 38.69 Mpps |
| Number of VLANs | 4094 |
| Security | |
| IGMP snooping | Yes |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| Management protocols | SNMP v1, v2c |
| Design | |
| Reset button | Yes |
| Product colour | Black |
| Rack mounting | Yes |
| Number of fans | 2 fan(s) |
| Certification | CE FCC ETL |
| Performance | |
| Noise level | 51 dB |
| Mean time between failures (MTBF) | 447228 h |
| Packet buffer memory | 0.5 MB |
| Power | |
| Power consumption (max) | 14.93 W |
| Power protection features | Over current, Short circuit |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power source | AC/PoE |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) power per port | 30 W |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Total Power over Ethernet (PoE) budget | 380 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE+ |
| Power protection features | Over current, Short circuit |
| Virtual LAN features | |
| VLAN support | Yes |
| Number of VLANs | 4094 |
| Virtual LAN features | Private VLAN, Tagged VLAN, Voice VLAN |
| Weight & dimensions | |
| Width | 17.3" (440 mm) |
| Depth | 7.68" (195 mm) |
| Height | 1.73" (44 mm) |
| Weight | 6.75 lbs (3.06 kg) |
| Technical details | |
| Product colour | Black |
| Noise level | 51 dB |
| Mean time between failures (MTBF) | 447228 h |
| Rack mounting | Yes |
| Memory | |
| Packet buffer memory | 0.5 MB |
| Certificates | |
| Certification | CE FCC ETL |
