Intel Core Ultra 7 155H (24MB Cache), 32GB LPDDR5x-SDRAM, 512GB SSD, 40.6 cm (16") Full HD+ 1920 x 1200 IPS, Intel Arc Graphics, NVIDIA RTX 1000 Ada (6GB GDDR6), WLAN, Webcam, Windows 11 Pro 64-bit
DELL
DELL Precision 5690 Intel Core Ultra 7 155H Mobile workstation 16" Full HD+ 32 GB LPDDR5x-SDRAM 512 GB SSD NVIDIA RTX 1000 Ada Wi-Fi 7 (802.11be) Windows 11 Pro Gray
Part number:
58JKH
Sale price
$2,396.42
Regular price
$3,475.87
Save
$1,079.45
31%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Windows 11 Pro 64-bit
- Intel Core Ultra 7 155H (24MB Cache)
- 40.6 cm (16") Full HD+ 1920 x 1200 IPS, NVIDIA RTX 1000 Ada (6GB GDDR6)
- 32GB LPDDR5x-SDRAM & 512GB SSD
Description
Take your ideas to the next level with *the world’s #1 workstations; optimized for performance, reliability and user experience.Specifications
| Design | |
|---|---|
| Product type | Mobile workstation |
| Market positioning | Business |
| Form factor | Clamshell |
| Product colour | Gray |
| Display | |
| HD type | Full HD+ |
| Pixel density | 142 ppi |
| Panel type | IPS |
| LED backlight | Yes |
| Display brightness | 500 cd/m² |
| Contrast ratio (typical) | 1300:1 |
| Touchscreen | No |
| Display resolution | 1920 x 1200 pixels |
| Display diagonal | 16" |
| Anti-glare screen | Yes |
| Maximum refresh rate | 60 Hz |
| RGB colour space | DCI-P3 |
| Colour gamut | 100% |
| Native aspect ratio | 16:10 |
| Processor | |
| Processor generation | Intel® Core™ Ultra (Series 1) |
| Processor cache type | Smart Cache |
| Processor cache | 24 MB |
| Processor model | 155H |
| Processor boost frequency | 4.8 GHz |
| Processor cores | 16 |
| Processor threads | 22 |
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 7 |
| Processor base power | 28 W |
| Maximum turbo power | 115 W |
| Efficient-core base frequency | 0.9 GHz |
| Performance-core base frequency | 1.4 GHz |
| Efficient-core Max Turbo Frequency | 3.8 GHz |
| Performance-core Max Turbo Frequency | 4.8 GHz |
| Performance cores | 6 |
| Efficient cores | 8 |
| Low Power Efficient-core Base Frequency | 700 MHz |
| Low Power Efficient-core Max Turbo Frequency | 2.5 GHz |
| Low Power Efficient-cores | 2 |
| Neural processor unit (NPU) | |
| Neural processor unit (NPU) | Intel AI Boost |
| Maximum frequency NPU | 1.4 GHz |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML, ONNX RT, OpenVINO, Windows ML |
| Memory | |
| Memory form factor | On-board |
| Internal memory | 32 GB |
| Internal memory type | LPDDR5x-SDRAM |
| Maximum internal memory | 32 GB |
| Memory channels | Dual-channel |
| Memory data transfer rate | 7467 MT/s |
| Storage | |
| SSD form factor | M.2 |
| Storage media | SSD |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 4.0 |
| Total storage capacity | 512 GB |
| Total SSDs capacity | 512 GB |
| SSD performance class | 40 |
| NVMe | Yes |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Graphics | |
| Discrete graphics card | Yes |
| Discrete graphics card memory | 6 GB |
| On-board graphics card family | Intel Arc Graphics |
| On-board graphics card | Yes |
| On-board graphics card model | Intel Arc Graphics |
| Discrete graphics card model | NVIDIA RTX 1000 Ada |
| Discrete graphics memory type | GDDR6 |
| On-board GPU manufacturer | Intel |
| Audio | |
| Number of microphones | 2 |
| Number of built-in speakers | 4 |
| Speakers manufacturer | Waves |
| Built-in microphone | Yes |
| Camera | |
| Front camera | Yes |
| Front camera resolution (numeric) | 2.07 MP |
| Front camera resolution | 1920 x 1080 pixels |
| Video capturing speed | 30 fps |
| Front camera HD type | Full HD |
| Infrared (IR) camera | Yes |
| Optical drive | |
| Optical drive type | No |
| Network | |
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| WLAN controller model | Intel Wi-Fi 7 BE200 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Bluetooth | Yes |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Intel |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Combo headphone/mic port | Yes |
| USB Power Delivery | Yes |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| Performance | |
| Gyroscope | Yes |
| Proximity sensor | Yes |
| Ambient light sensor | Yes |
| Accelerometer | Yes |
| Hall sensor | Yes |
| Keyboard | |
| Pointing device | Touchpad |
| Numeric keypad | No |
| Keyboard backlit | Yes |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Pro |
| Technical details | |
| Market positioning | Business |
| Form factor | Clamshell |
| Product colour | Gray |
| Discrete graphics card memory | 6 GB |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 6 |
| Battery capacity | 99.5 Wh |
| Battery recharge time | 3 h |
| Battery voltage | 11.55 V |
| Fast charging | Yes |
| Battery charge indicator | Yes |
| Battery weight | 12.8 oz (363 g) |
| Power | |
| AC adapter power | 165 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| Security | |
| Password protection | Yes |
| Cable lock slot type | Wedge |
| Trusted Platform Module (TPM) | Yes |
| Fingerprint reader | Yes |
| Cable lock slot | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | -598.4 - 120000" (-15.2 - 3048 m) |
| Non-operating altitude | -598.4 - 420000" (-15.2 - 10668 m) |
| Operating shock | 110 G |
| Non-operating shock | 160 G |
| Operating vibration | 0.66 G |
| Non-operating vibration | 1.3 G |
| Weight & dimensions | |
| Width | 13.9" (353.7 mm) |
| Depth | 9.46" (240.3 mm) |
| Height (front) | 0.807" (2.05 cm) |
| Height (rear) | 0.874" (2.22 cm) |
| Weight | 4.48 lbs (2.03 kg) |
| Packaging data | |
| Cables included | AC |
| Other features | |
| Ambient light sensor | Yes |
| WLAN controller model | Intel Wi-Fi 7 BE200 |
| On-board graphics card | Yes |
| Anti-glare screen | Yes |
| Sensors | |
| Proximity sensor | Yes |
| Ambient light sensor | Yes |
| Accelerometer | Yes |
| Packaging content | |
| Cables included | AC |
