UPSPro120W,24V Bat,100Ah, Pole/Wall Mt Al Enclosure
Features include 24VDC load controlled output, an advanced 20A PWM battery charge controller to protect against overcharging or over-discharging of the valve regulated sealed lead acid AGM batteries. The pole/wall mount aluminum enclosure has multiple ports for CAT5 cable, antenna cables/connectors or other cabling. They have thermostatically controlled power ventilation which turns on automatically when inside temperature exceeds 45C.
There is generous space inside the enclosures for customer electronics such as controllers, wireless AP or CPE cards, sensors, inverters, etc. There are mounting struts incorporated inside the enclosure to be able to mount DIN Rails or a flat metal or plywood plate. Equipment runs on battery power which isolates it from power line surges which is a main cause of outdoor equipment failure.
Tycon Systems
Tycon Systems UPS24-100-120 uninterruptible power supply (UPS) 120 W
Part number:
UPS24-100-120
$978.76
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- 24VDC System
- Weatherproof, UV resistant, Aluminum Outdoor Enclosure
- Powered from AC Mains Power and/or Solar
- Interior Space for Customer Electronics
- Pole/Wall Mounting
- Isolates Connected Equipment from Power Line Surges
- High Quality Maintenance Free AGM Batteries
- Advanced Battery Charge Controller Protects Against Overcharge and Over Discharge
Description
The UPSPro UPS24-100-120 outdoor backup power systems are designed for applications that require a flexible backup power source in order to maintain uninterrupted service to customers. The enclosure is powered from 120/240VAC. It is also solar ready (requires blocking diode with most panels) so a solar panel can be added as an alternate power source or to extend backup time.Features include 24VDC load controlled output, an advanced 20A PWM battery charge controller to protect against overcharging or over-discharging of the valve regulated sealed lead acid AGM batteries. The pole/wall mount aluminum enclosure has multiple ports for CAT5 cable, antenna cables/connectors or other cabling. They have thermostatically controlled power ventilation which turns on automatically when inside temperature exceeds 45C.
There is generous space inside the enclosures for customer electronics such as controllers, wireless AP or CPE cards, sensors, inverters, etc. There are mounting struts incorporated inside the enclosure to be able to mount DIN Rails or a flat metal or plywood plate. Equipment runs on battery power which isolates it from power line surges which is a main cause of outdoor equipment failure.
Specifications
| Power | |
|---|---|
| Output frequency | 50/60 Hz |
| Output power | 120 W |
| Input operation voltage (min) | 120 V |
| Input operation voltage (max) | 240 V |
| Maximum current | 5 A |
| Input frequency | 50/60 Hz |
| Features | |
| Output frequency | 50/60 Hz |
| Output power | 120 W |
| Input operation voltage (min) | 120 V |
| Input operation voltage (max) | 240 V |
| Maximum current | 5 A |
| Input frequency | 50/60 Hz |
| Battery | |
| Battery life (max) | 5 year(s) |
| Battery voltage | 24 V |
| Battery capacity | 100 Ah |
| Battery technology | Sealed Lead Acid (VRLA) |
| Design | |
| Form factor | Wallmount |
| Product colour | Gray |
| Housing material | Aluminum |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 65 °C |
| Technical details | |
| Output frequency | 50/60 Hz |
| Weight & dimensions | |
| Weight | 19.8 lbs (9 kg) |
| Width | 14" (356 mm) |
| Height | 15" (381 mm) |
| Depth | 12" (305 mm) |
| Packaging data | |
| Manual | Yes |
| Packaging content | |
| Manual | Yes |
