Intel Xeon D-2123IT (8MB Cache, 2.2GHz), 16GB DDR4-SDRAM (2666MHz), 480GB M.2, LAN
This product guide provides essential pre-sales information to understand the ThinkSystem SE350 edge server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SE350 and consider its use in IT solutions.
Introduction
The ThinkSystem SE350 is a purpose-built server that is half the width and significantly shorter than a traditional server, making it ideal for deployment in tight spaces. It can be mounted on a wall, stacked on a shelf or mounted in a rack. The ThinkSystem SE350 puts increased processing power, storage and network closer to where data is generated, allowing actions resulting from the analysis of that data to take place more quickly.
Suggested uses: edge computing (IoT, AI, machine learning), retail, video security, inventory management, building control, telecommunications, manufacturing, distribution
Did you know?
Customers looking for computing solutions at the edge of their networks often have to compromise -- to use either datacenter-class equipment which is too large and power hungry, or PC based equipment which can't run their enterprise level applications. The ThinkSystem SE350 fits the space between those two extremes. Its compact design, low power usage, and high performance are just the right combination for edge locations. The SE350 can be wall mounted, stacked on a shelf or installed in a rack. It is also designed to operate in rugged environments, up to 55°C.
Lenovo
Lenovo ThinkSystem SE350 server 480 GB Rack (1U) Intel® Xeon® D D-2123IT 2.2 GHz 16 GB DDR4-SDRAM
Part number:
7Z46A002NA
Sale price
$1,824.92
Regular price
$1,839.00
Save
$14.08
1%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Intel Xeon D-2123IT (8MB Cache, 2.2GHz)
- 16GB (2666MHz) DDR4-SDRAM (1 x 16)
Description
The ThinkSystem SE350 is a purpose-built server that is half the width and significantly shorter than a traditional server, making it ideal for deployment in tight spaces. It can be mounted on a wall, stacked on a shelf or mounted in a rack. The ThinkSystem SE350 puts increased processing power, storage and network closer to where data is generated, allowing actions resulting from the analysis of that data to take place more quickly.This product guide provides essential pre-sales information to understand the ThinkSystem SE350 edge server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SE350 and consider its use in IT solutions.
Introduction
The ThinkSystem SE350 is a purpose-built server that is half the width and significantly shorter than a traditional server, making it ideal for deployment in tight spaces. It can be mounted on a wall, stacked on a shelf or mounted in a rack. The ThinkSystem SE350 puts increased processing power, storage and network closer to where data is generated, allowing actions resulting from the analysis of that data to take place more quickly.
Suggested uses: edge computing (IoT, AI, machine learning), retail, video security, inventory management, building control, telecommunications, manufacturing, distribution
Did you know?
Customers looking for computing solutions at the edge of their networks often have to compromise -- to use either datacenter-class equipment which is too large and power hungry, or PC based equipment which can't run their enterprise level applications. The ThinkSystem SE350 fits the space between those two extremes. Its compact design, low power usage, and high performance are just the right combination for edge locations. The SE350 can be wall mounted, stacked on a shelf or installed in a rack. It is also designed to operate in rugged environments, up to 55°C.
Specifications
| Processor | |
|---|---|
| Thermal Monitoring Technologies | Yes |
| Thermal Design Power (TDP) | 60 W |
| Supported instruction sets | AVX 2.0 |
| Stepping | M1 |
| Scalability | 1S |
| Processor threads | 8 |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Skylake |
| Processor code | SR3ZW |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2400 MHz |
| Maximum number of PCI Express lanes | 32 |
| Maximum internal memory supported by processor | 512 GB |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Embedded options available | Yes |
| Bus type | UPI |
| Processor cache | 8 MB |
| Conflict-Free processor | Yes |
| Processor frequency | 2.2 GHz |
| Number of processors installed | 1 |
| Processor model | D-2123IT |
| Processor boost frequency | 3 GHz |
| Processor socket | BGA 2518 |
| Processor cores | 4 |
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® D |
| Memory | |
| Internal memory | 16 GB |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 4 |
| Memory clock speed | 2666 MHz |
| Maximum internal memory | 256 GB |
| Internal memory type | DDR4-SDRAM |
| ECC | Yes |
| Storage | |
| Number of SSDs supported | 4 |
| Total storage capacity | 480 GB |
| SSD interface | M.2 |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 10 |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| Maximum storage capacity | 15.68 TB |
| Network | |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet, Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| Serial ports quantity | 1 |
| Expansion slots | |
| PCI Express slots version | 3.0 |
| Optical drive | |
| Optical drive type | No |
| Design | |
| Optical drive type | No |
| Chassis type | Rack (1U) |
| Product colour | Black |
| Performance | |
| Compatible operating systems | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. Ubuntu Server certification. |
| Performance management | XClarity Enterprise |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Software | |
| Compatible operating systems | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. Ubuntu Server certification. |
| Processor special features | |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® OS Guard | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | No |
| Intel® Secure Key | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel QuickAssist Technology | No |
| Processor ARK ID | 136429 |
| CPU configuration (max) | 1 |
| Power | |
| Number of redundant power supplies installed | 1 |
| Redundant power supply (RPS) support | Yes |
| Technical details | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Ethernet interface type | 10 Gigabit Ethernet, Gigabit Ethernet |
| CPU configuration (max) | 1 |
| Chassis type | Rack (1U) |
| Management features | |
| Performance management | XClarity Enterprise |
| Weight & dimensions | |
| Width | 8.23" (209 mm) |
| Weight | 8.27 lbs (3.75 kg) |
| Height | 1.69" (43 mm) |
| Depth | 14.8" (376 mm) |
| Other features | |
| CPU configuration (max) | 1 |
