4U Ultra Compact Rackmount Chassis, 2 x 3.5", 1 x 5.25", 7 x Expansion Slot, 2 x USB 2.0, PS3, Black
iStarUSA
iStarUSA D-400S3 computer case Rack Black
Part number:
D-400S3
Sale price
$247.32
Regular price
$353.04
Save
$105.72
30%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Description
D-400S3 is an ultra compact industrial rackmount chassis with 13.7? in depth. The full size I/O supports all ATX motherboard and up to seven full-height add-on cards. Two external 3.5" drive bays are ideal for iStarUSA BPU-2535 to support up to 4 x 2.5" hard drives. Besides, there is one 5.25" slim drive bay for slim optical device. One 120mm and 80mm cooling fans in the front and additional one 80mm fans can be mounted in the rear to provide the best ventilation to prevent critical equipment from heat damage. D-400S3 provides server or cluster maximum reliability and performance.Specifications
| Design | |
|---|---|
| Material thickness | 0.0472" (1.2 mm) |
| Material | Aluminum, SECC |
| Number of 5.25" bays | 1 |
| Number of 3.5" bays | 2 |
| Rack mounting | Yes |
| Supported motherboard form factors | ATX, micro ATX |
| Suitable for | Home/Office |
| Reset button | Yes |
| LED indicators | Yes |
| Built-in speaker(s) | No |
| Product colour | Black |
| Number of expansion slots | 7 |
| Type | Server |
| Form factor | Rack |
| Rack capacity | 4U |
| Technical details | |
| Number of 5.25" bays | 1 |
| Number of 3.5" bays | 2 |
| Rack mounting | Yes |
| Supported motherboard form factors | ATX, micro ATX |
| Supported HDD sizes | 2.5,3.5" |
| Suitable for | Home/Office |
| Reset button | Yes |
| Built-in speaker(s) | No |
| Product colour | Black |
| Number of expansion slots | 7 |
| Type | Server |
| Form factor | Rack |
| Material | |
| Material | Aluminum, SECC |
| Material thickness | 0.0472" (1.2 mm) |
| Indication | |
| LED indicators | Yes |
| Ergonomics | |
| Reset button | Yes |
| LED indicators | Yes |
| Ports & interfaces | |
| Audio input | No |
| Audio output | No |
| USB 2.0 ports quantity | 2 |
| Cooling | |
| Front fans installed | 1x 80 mm/1x 120 mm |
| Front fans diameters supported | 80,120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 80 mm |
| Storage | |
| Supported HDD sizes | 2.5,3.5" |
| Card reader integrated | No |
| Weight & dimensions | |
| Width | 19" (482.6 mm) |
| Depth | 13.7" (348 mm) |
| Height | 7" (177.8 mm) |
| Material thickness | 0.0472" (1.2 mm) |
| Other features | |
| Power supply type | PS3 |
| Ventilation fan(s) | 2 x 80mm, 1 x 120mm |
| Power LED | Yes |
| Over current protection | Yes |
| Optional fans | 1 x 80mm |
| Main board size | 12 x 9.6" |
