4U Ultra Compact Rackmount Chassis, ATX, mATX, 2x 3.5'' Drive Bays, 1x Slim 5.25" Optical Drive Bay, 7x Expansion Slot, 2x USB 2.0, 1x 80mm fan, 1x 120mm, 1x 80mm Optional fan, Blue/Black
- Power and Reset Switch.
- Power and HDD LED.
- 120mm and 80mm Cooling Fans in the Front.
- Front Access USB2.0 Port.
D-400S3SE is an ultra compact industrial rackmount chassis with 13.7? in depth. The full size I/O supports all ATX motherboard and up to seven full-height add-on cards. Two external 3.5" drive bays are ideal for iStarUSA BPU-2535V2 to support up to 4 x 2.5" hard drives. Besides, there is one 5.25" slim drive bay for slim optical device. One 120mm and 80mm cooling fans in the front and additional one 80mm fans can be mounted in the rear to provide the best ventilation to prevent critical equipment from heat damage. D-400S3SE provides server or cluster maximum reliability and performance.
iStarUSA
iStarUSA D-400S3SE computer case Rack Black, Blue
Part number:
D-400S3SE
Sale price
$348.44
Regular price
$497.39
Save
$148.95
30%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Description
- Ultimate Compact Size 13.7" in Depth.- Power and Reset Switch.
- Power and HDD LED.
- 120mm and 80mm Cooling Fans in the Front.
- Front Access USB2.0 Port.
D-400S3SE is an ultra compact industrial rackmount chassis with 13.7? in depth. The full size I/O supports all ATX motherboard and up to seven full-height add-on cards. Two external 3.5" drive bays are ideal for iStarUSA BPU-2535V2 to support up to 4 x 2.5" hard drives. Besides, there is one 5.25" slim drive bay for slim optical device. One 120mm and 80mm cooling fans in the front and additional one 80mm fans can be mounted in the rear to provide the best ventilation to prevent critical equipment from heat damage. D-400S3SE provides server or cluster maximum reliability and performance.
Specifications
| Design | |
|---|---|
| Material thickness | 0.0472" (1.2 mm) |
| Material | Aluminum, SECC, Zinc steel |
| Number of 5.25" bays | 1 |
| Number of 3.5" bays | 2 |
| Rack mounting | Yes |
| Transport wheels | No |
| Supported motherboard form factors | ATX, micro ATX |
| Suitable for | Home/Office |
| Side window | No |
| Reset button | Yes |
| LED indicators | Fan fail, HDD, Power, Temperature |
| Certification | RoHS |
| Product colour | Black, Blue |
| Number of expansion slots | 7 |
| Type | Server |
| Form factor | Rack |
| Rack capacity | 4U |
| Technical details | |
| Number of 5.25" bays | 1 |
| Number of 3.5" bays | 2 |
| Rack mounting | Yes |
| Supported motherboard form factors | ATX, micro ATX |
| Supported HDD sizes | 3.5" |
| Suitable for | Home/Office |
| Side window | No |
| Reset button | Yes |
| Product colour | Black, Blue |
| Number of expansion slots | 7 |
| Type | Server |
| Form factor | Rack |
| Material | |
| Material | Aluminum, SECC, Zinc steel |
| Material thickness | 0.0472" (1.2 mm) |
| Indication | |
| LED indicators | Fan fail, HDD, Power, Temperature |
| Ergonomics | |
| Transport wheels | No |
| Reset button | Yes |
| LED indicators | Fan fail, HDD, Power, Temperature |
| Certificates | |
| Certification | RoHS |
| Power supply | |
| Power supply included | No |
| Ports & interfaces | |
| Audio input | No |
| Audio output | No |
| USB 2.0 ports quantity | 2 |
| Cooling | |
| Number of front fans supported (max) | 2 |
| Front fans diameters supported | 80,120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 80 mm |
| Storage | |
| Supported HDD sizes | 3.5" |
| Card reader integrated | No |
| Packaging content | |
| User guide | Yes |
| Remote control included | No |
| Weight & dimensions | |
| Width | 19" (482.6 mm) |
| Depth | 13.7" (348 mm) |
| Height | 7" (177.8 mm) |
| Material thickness | 0.0472" (1.2 mm) |
| Packaging data | |
| User guide | Yes |
| Remote control included | No |
| Other features | |
| On/off switch | Yes |
| Ventilation fan(s) | 1x 80mm, 1x 120mm |
| User guide | Yes |
| Power LED | Yes |
| Optional fans | 1x 80mm |
| Remote control included | No |
