0.59” (15 mm) x 3, 3 LCD, WXGA 3,072,000 (1280 x 800 x 3), 3000 lm, 3000:1, 10000 H, HDMI/VGA/S-Video/Composite/USB-B/USB-A/RJ45/Mic 3.5mm/Audio 3.5mm/RS232, 100-240V/ 50-60Hz, 365 x 138.7 x 310 mm, 4.4 Kg

Description

Low Total Cost of Ownership(TCO) for widescreen, short throw, high brightness projector

The VPL-SW235 short throw projector has a number of features to present high quality images while keeping low TCO. The projector also needs only 79cm to display a large 80-inch image on the screen, which fits perfectly in front of a white board leaving plenty of space. With the fuss-free installation and achievement of less glares or shadows during presentation, the short throw projector offers excellent usability.

Short throw distance
79cm for 80-inch image.

3LCD Color Light Output colour reproduction and high brightness
3000 lumen brightness with native WXGA (1280 x 800) 16:10 widescreen screen resolution.

Long-lasting lamp
10000 hours in Low mode.

Wireless presentation with tablet (iOS or Android)
The wireless presentation capability makes it easy to present files from your tablet device or smart phone.

Short throw distance
The VPL-SW235 offers a 0.46:1 throw ratio that produces a 2.03m (80-inch) diagonal screen size image from only 79cm (31-inch) away from the screen.

High image quality 3LCD natural and vivid colour images
Thanks to the optical system projecting three basic colours constantly each, the projector offers excellent light efficiency, which ensures colourful and bright images. High colour reproducibility is important especially when using colourful content, such as materials used in classrooms. The projector also has an excellent contrast ratio of 3000:1.

High brightness of 3000 lumen in High lamp mode
The VPL-SW235 features three brightness modes for different use – 'High' for naturally white presentations in bright rooms, 'Standard' for everyday use, and 'Low' for video in darkened rooms.The native WXGA (1280 x 800) 16:10 widescreen screen resolution panelis perfect for presentations direct from a laptop or PC.

Energy efficient with long-lasting lamp of 10000 hours
The lamp driver optimally controls the wattage of the lamp and achieves a long-lasting lamp time of 10000 hours with the brightness of lamp mode low. The recommended lamp replacement time is extended more than 66%, compared to the previous model.

Advanced energy-saving features
Advanced lamp technology enables robust energy-saving features. For example, greater brightness control in Auto Light Dimming mode saves considerable energy when the projector is left on without being used. During projection, Auto Picture Mode automaticallyadjusts light output to suit the projected scene. When you need to mute the picture temporarily, light output can be completely deactivated to minimise energy consumption.

Network presentation (LAN/Wireless LAN)
When the projector is installed on a LAN/Wireless LAN, presentations can be projected from any PC and Mac on the network. A tablet or smart phone can be connected at the same time. The wireless presentation capability makes it easy to present files from your tablet device or smart phone. You can project jpg, pdf and other supporting formats. Up to four users can project PC/Mac images simultaneously, while up to eight users can connect to one projector.For Windows/Mac, an application ”Projector Station for Network Presentation” is provided. For tablet/smartphone, an application is provided by Pixelworks, downloaded from the web.

Remote control for iOS device
Projector Remote is simple remote control app for Sony’s projectors.Networked projectors can be controlled by this remote app. Remote Control allows you to operate the projector with simple and easy-to-read buttons.

Networked control
Projector functions and status can also be managed and monitored remotely from any user's PC on the network.For Windows, an application ”Projector Station for Network Control” is provided.

USB Media viewer
Insert a USB drive to effortlessly display photos, images and graphics with no PC needed.

USB display
The projector allows you to display pictures and audio with one USB cable. You do not need to install any driver for this function. It is a convenient way to connect to the projector when you want to connect easily.

Built-in speaker
The projector includes a 16W monaural speaker.

Specifications

Projector
Colour light output	3000 ANSI lumens
Projector native resolution	WXGA (1280x800)
Native aspect ratio	16:10
Supported aspect ratios	4:3, 16:9, 16:10
Screen size compatibility	57 - 103"
Contrast ratio (typical)	3000:1
Vertical scan range	47 - 93 Hz
Horizontal scan range	14 - 93 kHz
Projector brightness (economic mode)	1700 ANSI lumens
Vertical synchronization (min)	0.047 kHz
Vertical synchronization (max)	0.093 kHz
Matrix size	0.59"
Keystone correction, vertical	± 7.5°
Horizontal synchronization (min)	14 kHz
Horizontal synchronization (max)	93 kHz
Projection technology	3LCD
Projector brightness	3000 ANSI lumens
Heat dissipation	1075 BTU/h
Light source
Light source type	Lamp
Service life of light source	6000 h
Lamp type	UHP
Lamp power	210 W
Service life of light source (economic mode)	10000 h
Lens system
Focus	Manual
Throw ratio	0.46:1
Video
Analog signal format system	NTSC 3.58, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Full HD	No
HD-Ready	Yes
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Supported graphics resolutions	1280 x 720 (HD 720), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 640 x 480 (VGA)
Ports & interfaces
VGA (D-Sub) ports quantity	3
HDMI ports quantity	1
USB 2.0 ports quantity	2
USB connector type	USB Type-A, USB Type-B
Composite video in	1
Audio (L/R) in	1
Microphone in	Yes
S-Video inputs quantity	1
Serial interface type	RS-232
PC Audio out	Yes
PC Audio in	Yes
DVI port	No
Component video (YPbPr/YCbCr) in	0
AC (power) in	Yes
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Storage
Card reader integrated	No
Features
HDCP	Yes
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Arabic, Simplified Chinese, Traditional Chinese, German, Dutch, English, Spanish, French, Greek, Hungarian, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
Number of OSD languages	24
Multimedia
Built-in speaker(s)	Yes
Number of built-in speakers	1
RMS rated power	16 W
Design
Market positioning	Short throw
Product type	Short throw projector
Product colour	White
Cable lock slot	Yes
Placement	Desktop
Display
Built-in display	No
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	315 W
Power source	AC
Power consumption (typical)	251 W
Power consumption (standby)	0.5 W
Power consumption (PowerSave)	219 W
Software
Other operating systems supported	Android, iOS
Operational conditions
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	20 - 80%
Operating temperature (T-T)	0 - 40 °C
Weight & dimensions
Weight	9.7 lbs (4.4 kg)
Width	14.4" (365 mm)
Depth	12.2" (310 mm)
Height	5.46" (138.7 mm)
Packaging content
Remote control included	Yes
Quick start guide	Yes
Manual	Yes
Cables included	AC, VGA
Batteries included	Yes
Other features
RS-232 ports	1
Maximum digital resolution	1600 x 1200 pixels
