32", 1920 x 1080, 1000:1, 9ms, IPS, HDMI, RS232C, RJ-45, USB 2.0
Slim & Light
The In-Cell Touch Open Frame has a touch function built into the display, allowing for the implementation of a slim design and a narrow bezel compared to general touch products that require additional touch parts (Film).
Clear Picture Quality
Compared to general touch products, TNF5P implements clear picture quality without milk effects caused by additional touch sensor film parts.
Design Flexibility
By providing integrated parts such as touchscreen, display, and webOS, users can realize free design for their own needs.
24hrs / 7days
TNF5P’s excellent durability allows for use in kiosks that require a full day of operation.
Wide Viewing Angle
IPS panel technology provides better control of the liquid crystals, which in turn allows the screen to be viewed at virtually any angle.
45-degree Tilt (Face up) Installation Possible
When a display is installed at low places, it is usually tilted for the user’s viewing comfort. Considering this, the installation with a max tilt of 45 degrees is supported.
10 Points of Multi-Touch
The TNF5P provides a more realistic touch sensation since it can recognize up to 10 points of multi-touch at once, and various touchbased user services can be provided through the screen.
High-Performance with webOS 6.0
webOS 6.0, upgraded in SoC* and web engine, is available on TNF5P for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI** and provides to SI or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, sample applications.
LG 32TNF5P-B signage display Interactive flat panel 32" LED 500 cd/m² Full HD Black Touchscreen WebOS
Part number:
32TNF5P-B
Sale price
$1,013.71
Regular price
$1,500.00
Save
$486.29
32%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Brightness : 500 nit
- Multi Touch Point : 10 Points (Max.)
- Interface : HDMI (2, HDCP 2.2/1.4), RS-232C In, RJ45(LAN), IR In, USB2.0 Type A, Audio Out, Touch USB (USB 2.0 Type B)
Description
New In-Cell Touch Open Frame for Optimal CustomizationSlim & Light
The In-Cell Touch Open Frame has a touch function built into the display, allowing for the implementation of a slim design and a narrow bezel compared to general touch products that require additional touch parts (Film).
Clear Picture Quality
Compared to general touch products, TNF5P implements clear picture quality without milk effects caused by additional touch sensor film parts.
Design Flexibility
By providing integrated parts such as touchscreen, display, and webOS, users can realize free design for their own needs.
24hrs / 7days
TNF5P’s excellent durability allows for use in kiosks that require a full day of operation.
Wide Viewing Angle
IPS panel technology provides better control of the liquid crystals, which in turn allows the screen to be viewed at virtually any angle.
45-degree Tilt (Face up) Installation Possible
When a display is installed at low places, it is usually tilted for the user’s viewing comfort. Considering this, the installation with a max tilt of 45 degrees is supported.
10 Points of Multi-Touch
The TNF5P provides a more realistic touch sensation since it can recognize up to 10 points of multi-touch at once, and various touchbased user services can be provided through the screen.
High-Performance with webOS 6.0
webOS 6.0, upgraded in SoC* and web engine, is available on TNF5P for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI** and provides to SI or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, sample applications.
Specifications
| Display | |
|---|---|
| LED backlight | Yes |
| Display number of colours | 16.7 million colors |
| Panel type | IPS |
| Number of simultaneous touchpoints | 10 |
| Touchscreen | Yes |
| Display technology | LED |
| Display diagonal | 32" |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 500 cd/m² |
| HD type | Full HD |
| Response time | 9 ms |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Panel life | 50000 h |
| Haze rate | 25% |
| Ports & interfaces | |
| Remote (IR) input | 1 |
| USB port | Yes |
| RS-232C | Yes |
| Ethernet LAN | Yes |
| HDMI ports quantity | 2 |
| Audio (L/R) out | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB version | 2.0 |
| USB ports quantity | 2 |
| USB 2.0 Type-B ports quantity | 1 |
| Design | |
| Product design | Interactive flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Bezel width (top) | 0.445" (1.13 cm) |
| Bezel width (side) | 0.445" (1.13 cm) |
| Bezel width (bottom) | 0.445" (1.13 cm) |
| Product colour | Black |
| Panel mounting interface | 200 x 200 mm |
| VESA mounting | Yes |
| Screen shape | Flat |
| Performance | |
| HDCP | Yes |
| HDCP version | 1.4 |
| Security algorithms | SNMP |
| Panel life | 50000 h |
| Power | |
| Heat dissipation | 164 BTU/h |
| Power consumption (max) | 65 W |
| Power consumption (typical) | 48 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Computer system | |
| Operating system installed | WebOS |
| Internal memory | 8 GB |
| Operating system version | 6.0 |
| Weight & dimensions | |
| Display width | 28.5" (723 mm) |
| Display depth | 1.54" (39.1 mm) |
| Display height | 16.5" (419.4 mm) |
| Display weight | 12.8 lbs (5.8 kg) |
| Packaging data | |
| Package width | 32" (812 mm) |
| Package depth | 5.59" (142 mm) |
| Package height | 20.1" (510 mm) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Technical details | |
| VESA mounting | Yes |
| Temperature indicator | Yes |
| Panel type | IPS |
| Playback modes | Rotation |
| Number of simultaneous touchpoints | 10 |
| Thin Client | |
| Operating system installed | WebOS |
| Internal memory | 8 GB |
| Other features | |
| Temperature indicator | Yes |
| Panel type | IPS |
| Playback modes | Rotation |
| Number of simultaneous touchpoints | 10 |
| Power consumption (max) | 65 W |
| Display technology | LED |
| Bezel width (top) | 0.445" (1.13 cm) |
| Bezel width (side) | 0.445" (1.13 cm) |
| Bezel width (bottom) | 0.445" (1.13 cm) |
