Zyxel NWA130BE BE11K 2x2 MU-MIMO, 2.4 GHz, 5 GHz, 6 GHz, 11000 Mbit/s, EAP, WPA2, WPA2-AES, WPA2-CCMP, WPA2-EAP, WPA2-Enterprise, WPA2-Enterprise-PEAP, WPA2-PSK,..., 10,100,300,1000,1200,2000,2500 Mbit/s
Zyxel
Zyxel NWA130BE BE11K 2x2 MU-MIMO 11000 Mbit/s White Power over Ethernet (PoE)
Part number:
NWA130BE
$152.68
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Description
Zyxel NWA130BE BE11K 2x2 MU-MIMO. 2.4 GHz, 5 GHz, 6 GHz, Maximum data transfer rate: 11000 Mbit/s. Security algorithms: EAP, WPA2, WPA2-AES, WPA2-CCMP, WPA2-EAP, WPA2-Enterprise, WPA2-Enterprise-PEAP, WPA2-PSK,.... Ethernet LAN data rates: 10,100,300,1000,1200,2000,2500 Mbit/s. Power over Ethernet (PoE). Product color: White. Power consumption (max): 24 WSpecifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 10,100,300,1000,1200,2000,2500 Mbit/s |
| Maximum data transfer rate | 11000 Mbit/s |
| Performance | |
| Full duplex | Yes |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Wireless isolation | Yes |
| Automatic channel selection | Yes |
| Auto Wireless Distribution System (WDS) | Yes |
| Auto MDI/MDI-X | Yes |
| Syslog | No |
| IGMP snooping | Yes |
| Country of origin | China |
| On/off switch | No |
| Reset button | Yes |
| Firmware upgradeable | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Bandwidth | 320 GHz |
| Frequency band | 6425 GHz |
| Number of users | 100 user(s) |
| Web-based management | Yes |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be |
| Ethernet LAN data rates | 10,100,300,1000,1200,2000,2500 Mbit/s |
| Channels quantity | 6 channels |
| Channel bandwidth | 320 MHz |
| Certification | Radio FCC Part 15C FCC Part 15E FCC Part 2.1091 ETSI EN 300 328 EN 301 893 Draft EN 303 687 EN 50385 EN 50665 EN IEC 62311,LP0002 EMC FCC Part 15B EN 301 489-1 EN 301 489-17 EN55032 EN55035 EN61000-3-2/-3 EN60601-1-2 BSMI CNS15936 Safety EN 62368-1 IEC 62368-1 BSMI CNS15598-1 |
| Maximum data transfer rate | 11000 Mbit/s |
| DHCP snooping | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Wi-Fi roaming | Yes |
| Band steering | Yes |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Built-in processor | Yes |
| Processor model | Qualcomm Networking Pro 1210 |
| Wireless LAN features | |
| Frequency band | 6425 GHz |
| Channels quantity | 6 channels |
| Network | |
| Number of users | 100 user(s) |
| Networking standards | IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be |
| Bandwidth | |
| Bandwidth | 320 GHz |
| Channel bandwidth | 320 MHz |
| Security | |
| Cable lock slot | Yes |
| Number of SSID supported | 8 |
| Auto Wireless Distribution System (WDS) | Yes |
| IGMP snooping | Yes |
| IP address filtering | No |
| Security algorithms | EAP, WPA2, WPA2-AES, WPA2-CCMP, WPA2-EAP, WPA2-Enterprise, WPA2-Enterprise-PEAP, WPA2-PSK, WPA2-Personal, WPA2-RADIUS, WPA2-TKIP, WPA3, WPA3-EAP, WPA3-Enterprise, WPA3-PSK, WPA3-Personal |
| MAC address filtering | Yes |
| Wireless Intrusion Detection System (WIDS) | Yes |
| DHCP snooping | Yes |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Service Set Identifier (SSID) features | Hidden SSID, Multiple SSIDs, SSID broadcast |
| Wireless Intrusion Prevention System (WIPS) | Yes |
| Management features | |
| Universal Plug and Play (UPnP) | Yes |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Syslog | No |
| Firmware upgradeable | Yes |
| Web-based management | Yes |
| Command-line interface (CLI) | No |
| Features | |
| 6 GHz | Yes |
| Full duplex | Yes |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Wireless isolation | Yes |
| Automatic channel selection | Yes |
| Auto MDI/MDI-X | Yes |
| Bandwidth | 320 GHz |
| Frequency band | 6425 GHz |
| Number of users | 100 user(s) |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be |
| Ethernet LAN data rates | 10,100,300,1000,1200,2000,2500 Mbit/s |
| Channels quantity | 6 channels |
| Channel bandwidth | 320 MHz |
| Cabling technology | 10/100/1000Base-T(X) |
| Maximum data transfer rate | 11000 Mbit/s |
| Tunnel forwarding | Yes |
| Fast roaming | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Duplex mode auto-negotiation | Yes |
| Automatic channel scanning | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Wi-Fi roaming | Yes |
| Band steering | Yes |
| Maximum data transfer rate (2.4 GHz) | 688 Mbit/s |
| Maximum data transfer rate (5 GHz) | 4324 Mbit/s |
| WLAN channel features | WLAN channel management |
| Virtual LAN features | Interface-based VLAN, Multicast VLAN |
| Maximum data transfer rate (6 GHz) | 5764 Mbit/s |
| Trusted Platform Module (TPM) | Yes |
| BeamForming | Yes |
| Spatial streams | 2x2 |
| Built-in processor | Yes |
| Processor model | Qualcomm Networking Pro 1210 |
| Protocols | |
| Universal Plug and Play (UPnP) | Yes |
| DHCP server | Yes |
| DHCP client | Yes |
| IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
| Ports & interfaces | |
| USB connector type | USB Type-C |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Power | |
| Power consumption (max) | 24 W |
| Power consumption (typical) | 24 W |
| Power supply | 12 W |
| Power over Ethernet (PoE) | Yes |
| Input current | 2 A |
| Power over Ethernet (PoE) type supported | Active PoE |
| DC voltage range | 12 V |
| Design | |
| Housing material | Aluminum, Metal, Plastic |
| Placement | Ceiling, Wall |
| Country of origin | China |
| On/off switch | No |
| Product colour | White |
| Reset button | Yes |
| LED indicators | LAN, Status, WLAN, Wi-Fi |
| Certification | Radio FCC Part 15C FCC Part 15E FCC Part 2.1091 ETSI EN 300 328 EN 301 893 Draft EN 303 687 EN 50385 EN 50665 EN IEC 62311,LP0002 EMC FCC Part 15B EN 301 489-1 EN 301 489-17 EN55032 EN55035 EN61000-3-2/-3 EN60601-1-2 BSMI CNS15936 Safety EN 62368-1 IEC 62368-1 BSMI CNS15598-1 |
| Cable lock slot | Yes |
| WPS push button | No |
| Cable lock slot type | Kensington |
| Recommended usage | Indoor |
| Market segment | Business |
| Antenna | |
| Antenna type | Internal |
| Polarization | Dual polarization |
| Antennas quantity | 6 |
| Antenna gain level (max) | 4 dBi |
| Antenna direction type | Omni-directional |
| Antenna features | Integrated antenna |
| Technical details | |
| Reset button | Yes |
| Firmware upgradeable | Yes |
| Polarization | Dual polarization |
| WPS push button | No |
| Sustainability compliance | Yes |
| Warranty period | 5 year(s) |
| Compliance certificates | CE, China RoHS, cTUVus |
| Processor | |
| Built-in processor | Yes |
| Certificates | |
| Certification | Radio FCC Part 15C FCC Part 15E FCC Part 2.1091 ETSI EN 300 328 EN 301 893 Draft EN 303 687 EN 50385 EN 50665 EN IEC 62311,LP0002 EMC FCC Part 15B EN 301 489-1 EN 301 489-17 EN55032 EN55035 EN61000-3-2/-3 EN60601-1-2 BSMI CNS15936 Safety EN 62368-1 IEC 62368-1 BSMI CNS15598-1 |
| Compliance certificates | CE, China RoHS, cTUVus |
| Indication | |
| LED indicators | LAN, Status, WLAN, Wi-Fi |
| Software | |
| Automatic channel scanning | Yes |
| Tunnel forwarding | Yes |
| Fast roaming | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Duplex mode auto-negotiation | Yes |
| Weight & dimensions | |
| Width | 9.84" (250 mm) |
| Depth | 6.3" (160 mm) |
| Weight | 28.5 oz (808 g) |
| Height | 1.85" (47 mm) |
| Package width | 11" (280 mm) |
| Package depth | 7.13" (181 mm) |
| Package height | 2.6" (66 mm) |
| Package weight | 2.27 lbs (1.03 kg) |
| Packaging data | |
| Quick start guide | Yes |
| Mounting kit | Yes |
| PoE adapter included | No |
| Package type | Box |
| Package width | 11" (280 mm) |
| Package depth | 7.13" (181 mm) |
| Package height | 2.6" (66 mm) |
| Package weight | 2.27 lbs (1.03 kg) |
| AC adapter included | No |
| Packaging content | |
| Quick start guide | Yes |
| Mounting kit | Yes |
| PoE adapter included | No |
| AC adapter included | No |
| Quantity per pack | 1 pc(s) |
| Package type | Box |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Sustainability | |
| Sustainability compliance | Yes |
| Other features | |
| Polarization | Dual polarization |
| WPS push button | No |
| Logistics data | |
| Country of origin | China |
| Quantity per pack | 1 pc(s) |
| Warranty period | 5 year(s) |
