7100-Lumen Professional Installation Projector w/lens and 4K support
Sharp
Sharp NP-PV710UL-W1-13ZL data projector Standard throw projector 7100 ANSI lumens LCD DCI 4K (4096x2160) White
Part number:
NP-PV710UL-W1-13ZL
$3,918.33
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- 4K Ready - Display stunning 4K 60P content using NEC’s proprietary high performance video processing/scaling chip without the loss of critical details. HDR10 and BT.2020 signals from “Ultra HD Blu-ray” and “4K TV broadcasting” are supported on all digital inputs
- Basic control of competitors product reducing the need for reprogramming of a control system. (call NEC for complete list)
- Integrated software applications such as AMX Beacon, Crestron Roomview, Extron XTP and PJ link allow for complete interactivity and control
- 7100-lumen (Center: 7400lm) brightness enhances images for most applications
- ProAssist is software for controlling the projector and adjusting the projected image on the screen from a computer via a network. It allows necessary adjustments to be carried out easily when combining several projectors together to project a large screen in a classroom, meeting room, auditorium or other large space
Description
NEC's PV710UL-W1-13 (white cabinet) is a 7100-lumen (Center: 7400lm) LCD laser projector with advanced professional installation features for higher education and corporate users. With its multitude of digital inputs, connection to any computer or high definition device is possible. Enjoy design and installation flexibility with a complete line of optional motorized lenses (lens shift, focus and zoom), roll free installation capabilities. The HDBaseT input provides a single connection for uncompressed full HD digital video, audio, ethernet power and various control signals.Specifications
| Projector | |
|---|---|
| Projector native resolution | DCI 4K (4096x2160) |
| Native aspect ratio | 16:10 |
| Screen size compatibility | 30 - 150" |
| Projection distance | 29.1 - 822.8" (0.74 - 20.9 m) |
| Contrast ratio (typical) | 3000000:1 |
| Vertical scan range | 50 - 85 Hz |
| Horizontal scan range | 24 - 100 kHz |
| Vertical synchronization (min) | 0.05 kHz |
| Vertical synchronization (max) | 0.085 kHz |
| Keystone correction, vertical | 30° |
| Keystone correction, horizontal | 30° |
| Horizontal synchronization (min) | 24 kHz |
| Horizontal synchronization (max) | 100 kHz |
| Projection technology | LCD |
| Projector brightness | 7100 ANSI lumens |
| Light source | |
| Light source type | Laser |
| Service life of light source | 20000 h |
| Light source brightness | 8000 lm |
| Lens system | |
| Zoom capability | Yes |
| Focus | Manual |
| Focal length range | 24.2 - 48.6 mm |
| Throw ratio | 1.46 - 2.95:1 |
| Zoom type | Manual |
| Video | |
| Analog signal format system | NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM |
| Full HD | Yes |
| 3D | No |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
| Ports & interfaces | |
| HDMI connector type | Full-size |
| HDBaseT port | Yes |
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 2 |
| USB 2.0 ports quantity | 1 |
| Composite video in | 0 |
| Audio (L/R) in | 0 |
| Serial interface type | RS-232 |
| HDMI version | 2.0 |
| DVI port | No |
| Component video (YPbPr/YCbCr) in | 0 |
| AUX in | Yes |
| AC (power) in | Yes |
| Network | |
| Smart TV | No |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet LAN (RJ-45) ports | 1 |
| Storage | |
| Card reader integrated | No |
| Features | |
| HDCP | Yes |
| Noise level | 40 dB |
| Noise level (economic mode) | 31 dB |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
| High Dynamic Range (HDR) supported | Yes |
| Multimedia | |
| Built-in speaker(s) | No |
| Design | |
| Product type | Standard throw projector |
| Product colour | White |
| Display | |
| Built-in display | No |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 456 W |
| Power source | AC |
| Power consumption (typical) | 456 W |
| Operational conditions | |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage temperature (T-T) | -10 - 50 °C |
| Storage relative humidity (H-H) | 20 - 80% |
| Operating temperature (T-T) | 0 - 45 °C |
| Operating altitude | 78.7 - 102362.2" (2 - 2600 m) |
| Weight & dimensions | |
| Package width | 23.3" (591 mm) |
| Package depth | 23.3" (591 mm) |
| Package height | 10.2" (259 mm) |
| Weight | 24.7 lbs (11.2 kg) |
| Width | 19.8" (503 mm) |
| Depth | 16.2" (411 mm) |
| Height | 6.61" (168 mm) |
| Package weight | 29.5 lbs (13.4 kg) |
| Packaging content | |
| Remote control included | Yes |
