AX3000 Dual Band WiFi 6 PoE+
Faster speeds are possible on this WiFi 6 access point with 1024-QAM, OFDMA, and MU-MIMO technologies. MU-MIMO technology processes multiple data streams simultaneously, increasing real-time WiFi performance when multiple devices access the network. The wireless access point features access control, bandwidth control, and band steering. The low-profile housing design blends into most environments, and includes a convenient wall / ceiling mounting plate.
Easily manage and configure TRENDnet’s AX3000 Dual Band WiFi 6 PoE+ Access Point remotely with TRENDnet Hive. TRENDnet Hive is a remote network cloud manager that reduces management time and cost. No additional hardware, server, or personal cloud is required with this WiFi 6 access point and TRENDnet’s reliable cloud service.
Trendnet
Trendnet TEW-923DAP wireless access point 2975 Mbit/s White Power over Ethernet (PoE)
Part number:
TEW-923DAP
Sale price
$101.83
Regular price
$104.99
Save
$3.16
3%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- High performance AX3000 PoE+ access point
- AX3000 Dual Band: 2402Mbps (5GHz) + 573Mbps (2.4GHz) bands
- Two concurrent WiFi bands maximize device networking speeds
- OFDMA and MU-MIMO technology boosts performance in a busy environment
- Access Point and Repeater modes
- Supports up to WPA3 encryption
- 1 x 2.5GBASE-T PoE+ LAN port
- Low-profile blends into most environments
- Includes wall / ceiling mounting plate
- Remote cloud management with TRENDnet Hive (Additional fee applies)
- NDAA / TAA compliant (U.S. and Canada only)
Description
TRENDnet’s high-performance AX3000 Dual Band WiFi 6 PoE+ Access Point, model TEW-923DAP, features two concurrent WiFi bands to maximize networking speeds with the latest WiFi 6 technology. The two separate high-speed WiFi 6 bands provide speeds up to 2402Mbps on the 5GHz band and 573Mbps on the 2.4GHz band. The access point also supports Access Point (AP) and Repeater modes.Faster speeds are possible on this WiFi 6 access point with 1024-QAM, OFDMA, and MU-MIMO technologies. MU-MIMO technology processes multiple data streams simultaneously, increasing real-time WiFi performance when multiple devices access the network. The wireless access point features access control, bandwidth control, and band steering. The low-profile housing design blends into most environments, and includes a convenient wall / ceiling mounting plate.
Easily manage and configure TRENDnet’s AX3000 Dual Band WiFi 6 PoE+ Access Point remotely with TRENDnet Hive. TRENDnet Hive is a remote network cloud manager that reduces management time and cost. No additional hardware, server, or personal cloud is required with this WiFi 6 access point and TRENDnet’s reliable cloud service.
Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 2500 Mbit/s |
| Maximum data transfer rate | 2975 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Reset button | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Receiver sensitivity | 802.11a: -72 dBm (typical) @ 54Mbps 802.11b: -97 dBm (typical) @ 11Mbps 802.11g: -75 dBm (typical) @ 54Mbps 802.11n (2.4 GHz): -72 dBm (typical) @ 300Mbps 802.11n (5 GHz): -70 dBm (typical) @ 300Mbps 802.11ac: -60 dBm (typical) @ 867Mbps 802.11ax (2.4GHz): -60 dBm (typical) @ 573Mbps 802.11ax (5GHz): -52 dBm (typical) @ 2402Mbps |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN data rates | 2500 Mbit/s |
| Certification | CE FCC |
| Maximum data transfer rate | 2975 Mbit/s |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Band steering | Yes |
| Network | |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
| Management features | |
| Universal Plug and Play (UPnP) | Yes |
| Features | |
| 6 GHz | No |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Receiver sensitivity | 802.11a: -72 dBm (typical) @ 54Mbps 802.11b: -97 dBm (typical) @ 11Mbps 802.11g: -75 dBm (typical) @ 54Mbps 802.11n (2.4 GHz): -72 dBm (typical) @ 300Mbps 802.11n (5 GHz): -70 dBm (typical) @ 300Mbps 802.11ac: -60 dBm (typical) @ 867Mbps 802.11ax (2.4GHz): -60 dBm (typical) @ 573Mbps 802.11ax (5GHz): -52 dBm (typical) @ 2402Mbps |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN data rates | 2500 Mbit/s |
| Maximum data transfer rate | 2975 Mbit/s |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Band steering | Yes |
| Maximum data transfer rate (2.4 GHz) | 573 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2402 Mbit/s |
| Security | |
| Number of SSID supported | 16 |
| Security algorithms | WPA2, WPA3-Enterprise, WPA3-SAE |
| Protocols | |
| Universal Plug and Play (UPnP) | Yes |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Power | |
| Power consumption (max) | 17.4 W |
| Power over Ethernet (PoE) | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Design | |
| Placement | Ceiling, Wall |
| Product colour | White |
| Reset button | Yes |
| LED indicators | Yes |
| Certification | CE FCC |
| Antenna | |
| Antenna type | Internal |
| Antenna gain level (max) | 5.5 dBi |
| Technical details | |
| Reset button | Yes |
| Receiver sensitivity | 802.11a: -72 dBm (typical) @ 54Mbps 802.11b: -97 dBm (typical) @ 11Mbps 802.11g: -75 dBm (typical) @ 54Mbps 802.11n (2.4 GHz): -72 dBm (typical) @ 300Mbps 802.11n (5 GHz): -70 dBm (typical) @ 300Mbps 802.11ac: -60 dBm (typical) @ 867Mbps 802.11ax (2.4GHz): -60 dBm (typical) @ 573Mbps 802.11ax (5GHz): -52 dBm (typical) @ 2402Mbps |
| Certificates | |
| Certification | CE FCC |
| Indication | |
| LED indicators | Yes |
| Weight & dimensions | |
| Width | 6.3" (160 mm) |
| Depth | 6.3" (160 mm) |
| Weight | 13.4 oz (380 g) |
| Height | 1.18" (30 mm) |
| Packaging data | |
| Quick start guide | Yes |
| Cables included | LAN (RJ-45) |
| Packaging content | |
| Quick start guide | Yes |
| Cables included | LAN (RJ-45) |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
