1.3" touchscreen, Ethernet, 2x LAN, 2x WAN, Quad-core ARM Cortex-A57 at 1.7 GHz, 2GB DDR4, 1U rack, AC/DC, internal, 50W
Ubiquiti
Ubiquiti Gateway Pro gateway/controller 1000 Mbit/s
Part number:
UXG-Pro-US
$524.50
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- (1) 10G SFP+ and (1) GbE WAN port
- (1) 10G SFP+ and (1) GbE LAN port
- 1U rackmount
- DC power backup-ready
Description
Dual-WAN security gateway designed to protect medium to large-sized networks with enterprise-class firewall configuration and threat management features.Specifications
| Design | |
|---|---|
| LED indicators | Yes |
| Mounting type | Rack mounting |
| Rack capacity | 1U |
| Product colour | Gray |
| Enclosure material | Aluminum |
| Features | |
| Interface | Ethernet |
| Built-in processor | Yes |
| Processor frequency | 1700 MHz |
| Number of processors installed | 1 |
| Performance | |
| Built-in processor | Yes |
| Processor frequency | 1700 MHz |
| Number of processors installed | 1 |
| Internal memory | 2048 MB |
| Control display unit | Yes |
| Processor model | Cortex-A57 |
| Processor manufacturer | ARM |
| Mounting type | Rack mounting |
| Rack capacity | 1U |
| Product colour | Gray |
| Enclosure material | Aluminum |
| Network | |
| Ethernet LAN data rates | 1000 Mbit/s |
| Ports & interfaces | |
| WAN connection | Ethernet (RJ-45), SFP |
| Ethernet LAN (RJ-45) ports | 2 |
| Management features | |
| Reset button | Yes |
| Power | |
| Power supply | 50 W |
| Input voltage | 125 V |
| Input frequency | 60 Hz |
| Input current | 2.7 A |
| DC input voltage | 11.5 V |
| Power consumption (max) | 30 W |
| Weight & dimensions | |
| Weight | 7.54 lbs (3.42 kg) |
| Width | 17.4" (442.4 mm) |
| Height | 1.72" (43.7 mm) |
| Depth | 11.2" (285.6 mm) |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Sustainability | |
| Sustainability compliance | Yes |
| Technical details | |
| Built-in processor | Yes |
| Interface | Ethernet |
| Processor frequency | 1700 MHz |
| Number of processors installed | 1 |
| Sustainability compliance | Yes |
| Harmonized System (HS) code | 85176990 |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Indication | |
| LED indicators | Yes |
| Memory | |
| Internal memory | 2048 MB |
| Display | |
| Touchscreen | Yes |
| Display diagonal | 1.3" |
| Control display unit | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
