Better Choice For High-Density & High-Speed Networking

Description

No need for cascading with sufficient ports
Feature wire-speed forwarding for efficient communication

It provides 48 10/100/1000M auto-negotiation RJ45 ports and 2 1000M independent SFP slots, its full-duplex transmission rate can reach 2000 Mbps.
Compared with the traditional connection method of cascading two 24-port Gigabit switches, its high-density ports can easily solve the problems of large space occupation and high failure rate encountered in the project.

When multi ports synchronous forwarding, it can avoid network congestion caused by the uplink bandwidth bottleneck of two 24-port Gigabit cascading. All ports realize the wire-speed forwarding, and easily compatible with all office scenarios.

One-key VLAN, Enhance The Network Security
Under the VLAN mode, ports 1 to 46 cannot communicate with each other,
but can communicate with uplink ports 47 to 50, isolating broadcast storms and enhancing network security.

Dual 6kV Lightning Protection
This switch provides 6 kV lightning protection for both Ethernet ports and the power supply,
and supports over-temperature, over-voltage and surge current protection.

12 Mb Large Buffer
With 12 Mb large buffer, the switch can meet the needs of such network applications with burst traffic as search engine, IPTV, and P2P downloads, ensuring no packet loss, timely transmission of large files, and smoothness of videos.

Various Mounting Options
It supports Desktop/Wall/Rack Mounting,
and is flexible & practical enough for actual network engineering.

Specifications

Management features
Switch type	Unmanaged
Ports & interfaces
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	50
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Network
Cable types supported	Cat5, Cat5e
MAC address auto-learning supported	Yes
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z
10G support	No
Data transmission
MAC address table	8000 entries
Switching capacity	1000 Gbit/s
Store-and-forward	Yes
Forwarding rate	74.4 Mpps
Design
Product colour	Gray
LED indicators	Yes
Rack mounting	Yes
Power
Power consumption (max)	48 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	4 A
DC input voltage	12 V
Power source	AC
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	17.3" (440 mm)
Depth	9.45" (240 mm)
Height	1.73" (44 mm)
Technical details
Product colour	Gray
Rack mounting	Yes
Indication
LED indicators	Yes
