IEEE 802.11a/b/g/n/ac, 2.4/5GHz, MU-MIMO

Description

The GWN7615 include support for advanced QoS, low-latency real-time applications, mesh networks , captive portals, 200+ concurrent clients per AP and dual Gigabit network ports with PoE/PoE+, the GWN7615 can be us ed to create a scalable solution as big or small as needed for the deployment scenario, from office buildings to reta il locations, hotels and more.To ensure easy installation and management, the GWN7615 uses a controller-less distributed network management design in which the controller is embedded within the product’s web user interface. The GWN7615 is also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management pl atforms. It is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstr eam’s Wi-Fi-capable IP phones.

Specifications

Data transmission
Ethernet LAN data rates	10,100,1000 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Quality of Service (QoS) support	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10,100,1000 Mbit/s
Certification	FCC, CE, RCM, IC
MIMO type	Multi User MIMO
MIMO	Yes
Network
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Management features
Quality of Service (QoS) support	Yes
Certificates
Certification	FCC, CE, RCM, IC
Features
2.4 GHz	Yes
5 GHz	Yes
Quality of Service (QoS) support	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10,100,1000 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Security
Number of SSID supported	16
Security algorithms	WEP, WPA, WPA2, WPA2-PSK
Protocols
Supported protocols	IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
Power
Power consumption (max)	12.5 W
Power over Ethernet (PoE)	Yes
Design
Placement	Wall
Product colour	White
Certification	FCC, CE, RCM, IC
Antenna
Antenna type	Internal
Weight & dimensions
Width	8.09" (205.4 mm)
Depth	1.81" (45.9 mm)
Weight	17.6 oz (500 g)
Height	8.09" (205.4 mm)
Package width	10.2" (258 mm)
Package depth	9.72" (247 mm)
Package height	3.39" (86 mm)
Package weight	30.6 oz (867.3 g)
Packaging data
Package width	10.2" (258 mm)
Package depth	9.72" (247 mm)
Package height	3.39" (86 mm)
Package weight	30.6 oz (867.3 g)
