Unmanaged 5 x 2.5GBASE-T ports, 10/100/1000Mbps, 100 – 240V AC, 50/60Hz, 900 g, Black

Key Features

• Fanless design eliminates noise
• Wall mountable for installation flexibility

Description

Expand your network’s bandwidth and reduce traffic bottlenecks with TRENDnet’s Unmanaged 2.5G PoE+ Switches. These 2.5G PoE+ switches come equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. Each high-speed 2.5G PoE+ switch features a durable metal enclosure and can be mounted to the wall for setup flexibility. The fanless design lowers energy consumption and eliminates distracting operating noise. TRENDnet’s reliable 2.5G PoE+ switches are cost-effective solutions to increase your network’s throughput. A 55W total PoE power budget on this PoE+ switch supplies up to four PoE+ devices with up to 30W per port.

2.5G Ports
Equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling.

Wall Mountable
The 2.5G PoE+ switches feature a metal housing with a convenient wall mountable design for greater installation flexibility.

PoE+
A 55W total PoE power budget on this PoE+ switch supplies up to four PoE+ devices with up to 30W per port.

Easy Installation
No configuration needed, simply connect network devices to the 2.5G PoE+ switch

Fanless
Fanless design lowers energy consumption and eliminates operating noise

Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 12KB) for increased performance

LED Indicators
LED indicators convey port status

Specifications

Management features
Switch type	Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Power connector	DC-in jack
Network
Cable types supported	Cat5e
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Full duplex	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
10G support	No
Half duplex	Yes
Data transmission
Jumbo frames	12000
Packet buffer memory	1.5 MB
MAC address table	16000 entries
Switching capacity	25 Gbit/s
Jumbo frames support	Yes
Forwarding rate	18.6 Mpps
Design
Wall mountable	Yes
Product colour	Black
LED indicators	Activity, Link, PoE, Power
Housing material	Metal
Certification	CE, FCC
Performance
Fanless	Yes
MTBF (PoE)	830917 h
Packet buffer memory	1.5 MB
Harmonized System (HS) code	85176990
Power
Power consumption (max)	7.83 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power source	AC/DC
Power cable length	59.1" (1.5 m)
Power connector	DC-in jack
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	55 W
Power over Ethernet (PoE) ports quantity	4
Power over Ethernet (PoE)	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90%
Weight & dimensions
Width	11.3" (286 mm)
Depth	4.02" (102 mm)
Height	1.06" (27 mm)
Weight	31.7 oz (900 g)
Packaging content
Quick start guide	Yes
Cables included	DC
Technical details
Product colour	Black
Housing material	Metal
Memory
Packet buffer memory	1.5 MB
Certificates
Certification	CE, FCC
Indication
LED indicators	Activity, Link, PoE, Power
Packaging data
Quick start guide	Yes
Cables included	DC
Other features
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Logistics data
Harmonized System (HS) code	85176990
