Layer 2 FortiGate switch controller compatible PoE+ switch with 8 x GE RJ45 ports, 2 x GE SFP, Fanless with automatic Max 130W POE output limit.

Key Features

• Entry level switch
• 8 GE ports
• PoE+ capable
• Desktop to wiring closet
• 2 GE SFP uplink ports

Description

Security, Performance, and Manageability
The FortiSwitch™ Secure Access Family delivers outstanding security, performance, and manageability. Secure, simple, and scalable, FortiSwitch is the right choice for threatconscious businesses of all sizes. Tightly integrated into the Fortinet Security Fabric via FortiLink, FortiSwitch can be managed directly from the familiar FortiGate interface. This single-pane-of-glass management provides complete visibility and control of users and devices on the network regardless of how they connect. This makes the FortiSwitch ideal for SD-Branch and campus deployments with applications that range from desktop to data center aggregation, enabling businesses to converge their security and network access.

Security Fabric Integration through FortiLink
FortiLink is an innovative proprietary management protocol that allows our FortiGate Next-Generation Firewall to seamlessly manage any FortiSwitch. FortiLink enables the FortiSwitch to become a logical extension of the FortiGate, integrating it directly into the Fortinet Security Fabric. This management option reduces complexity and decreases management costs as network security and access layer functions are enabled and managed through a single console. FortiLink integration enables centralized policy management, including role-based access and control, making it easy to implement and manage.

Specifications

Virtual LAN features
Number of VLANs	4000
Data transmission
Number of VLANs	4000
Latency (1 Gbps)	4 µs
Packet buffer memory	0.512 MB
MAC address table	8000 entries
Switching capacity	20 Gbit/s
Performance
Packet buffer memory	0.512 MB
Memory type	DDR3-SDRAM
Internal memory	256 MB
Flash memory	32 MB
Fanless	Yes
Technical details
Product colour	White
Rack mounting	Yes
Management features
Switch type	Managed
Web-based management	Yes
Switch layer	L2+
Configuring Location Settings (CLI)	Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity	2
Console port	RJ-45
Network
Networking standards	IEEE 802.3af, IEEE 802.3at
Spanning tree protocol	Yes
Number of VLANs	4000
Link aggregation	Yes
Security
Security algorithms	HTTPS, SNMP, SNMPv2, SNMPv3, SSH
Access Control List (ACL)	Yes
Certificates
Certification	FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2
Memory
Packet buffer memory	0.512 MB
Memory type	DDR3-SDRAM
Internal memory	256 MB
Flash memory	32 MB
Design
Product colour	White
LED indicators	Yes
Certification	FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2
Rack mounting	Yes
Indication
LED indicators	Yes
Power
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	74.4 W
Power source	AC
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port	65 W
Power over Ethernet (PoE)	Yes
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	0 - 45 °C
Heat dissipation	34.12 BTU/h
Weight & dimensions
Width	9.84" (250 mm)
Depth	8.23" (209 mm)
Height	1.73" (44 mm)
Weight	3.75 lbs (1.7 kg)
