(1) 10/100/1000 Ethernet Port, (1) 10/100 Ethernet Port, 1.2+ Gbps, 128-bit AES, airOS F, SISO/MIMO
Ubiquiti
Ubiquiti AF-11 bridge/repeater Network bridge 1000 Mbit/s White
Part number:
AF-11
$1,055.49
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Full duplex Point-to-Point radio
- 11 GHz frequency operation
- Up to 1.2+ Gbps throughput
- Proprietary INVICTUS™ processor
- Integrates with airFiber® 11 GHz antennas
- Utilizes distinct Rx and Tx frequencies
- Accepts PoE or DC power
- Secure 128-bit AES encryption
Description
Breaking free from the congested 5 GHz band, airFiber® 11 is the first modular airFiber radio system purpose-built for the 11 GHz licensed frequency market. Housed in a compact, highly efficient form factor, airFiber 11 delivers amazing wireless gigabit+ performance, low latency, and long range, making it ideal for carrier backhaul, building-to-building enterprise use, or public safety applications.Specifications
| Data transmission | |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Wireless LAN features | |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (5 GHz) |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ports & interfaces | |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Security | |
| Security algorithms | 128-bit AES |
| Features | |
| Product type | Network bridge |
| Product colour | White |
| Processor model | INVICTUS 2 IC |
| LED indicators | Yes |
| Power | |
| Power source type | DC, PoE |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 50 °C |
| Management features | |
| LED indicators | Yes |
| Certificates | |
| Certification | FCC Part 101, ETSI EN 302 217 |
| Technical details | |
| Product colour | White |
| Harmonized System (HS) code | 85176990 |
| Weight & dimensions | |
| Weight | 4.98 lbs (2.26 kg) |
| Width | 4.41" (112 mm) |
| Depth | 3.39" (86 mm) |
| Height | 12.9" (327 mm) |
| Processor | |
| Processor model | INVICTUS 2 IC |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
