24 x GE RJ45, 4 x 10GE SFP+, 1 x RJ-45 Console, 1RU, 128 Gbps, 190 Mpps, 32 K, 512 MB DDR3, 2.03 kg
The FortiSwitch™ Secure Access Family delivers outstanding security, performance, and manageability. Secure, simple, and scalable, FortiSwitch is the right choice for threat-conscious businesses of all sizes.
Tightly integrated into the Fortinet Security Fabric via FortiLink, FortiSwitch can be managed directly from the familiar
FortiGate interface. This single-pane-of-glass management provides complete visibility and control of users and devices on the network regardless of how they connect. This makes the FortiSwitch ideal for SD-Branch and campus deployments with applications that range from desktop to data center
aggregation, enabling businesses to converge their security and network access.
Security Fabric Integration through FortiLink
FortiLink is an innovative proprietary management protocol that allows our FortiGate Next-Generation Firewall to seamlessly manage any FortiSwitch. FortiLink enables the FortiSwitch to become a logical extension of the FortiGate, integrating it directly into the Fortinet Security Fabric.
This management option reduces complexity and decreases management costs as network security and access layer functions are enabled and managed through a single console. FortiLink integration enables centralized policy management, including role-based access and control, making it easy to implement and manage.
Fortinet
Fortinet FS-124F network switch Managed L2 Gigabit Ethernet (10/100/1000) 1U White
Part number:
FS-124F
Sale price
$494.40
Regular price
$765.00
Save
$270.60
35%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Designed for installations from desktops to wiring closets
- Ideal for SD-Branch deployments
- Centralized security and access management from FortiGate interfaces with FortiLink
- Supports non-FortiLink deployments through onboard GUI, API, or command line configuration
- Up to 48 ports in a compact 1 RU form factor
- Stackable up to 300 switches per FortiGate, depending on model
- Supports wire-speed switching and store and forward forwarding mode
Description
Security, Performance, and ManageabilityThe FortiSwitch™ Secure Access Family delivers outstanding security, performance, and manageability. Secure, simple, and scalable, FortiSwitch is the right choice for threat-conscious businesses of all sizes.
Tightly integrated into the Fortinet Security Fabric via FortiLink, FortiSwitch can be managed directly from the familiar
FortiGate interface. This single-pane-of-glass management provides complete visibility and control of users and devices on the network regardless of how they connect. This makes the FortiSwitch ideal for SD-Branch and campus deployments with applications that range from desktop to data center
aggregation, enabling businesses to converge their security and network access.
Security Fabric Integration through FortiLink
FortiLink is an innovative proprietary management protocol that allows our FortiGate Next-Generation Firewall to seamlessly manage any FortiSwitch. FortiLink enables the FortiSwitch to become a logical extension of the FortiGate, integrating it directly into the Fortinet Security Fabric.
This management option reduces complexity and decreases management costs as network security and access layer functions are enabled and managed through a single console. FortiLink integration enables centralized policy management, including role-based access and control, making it easy to implement and manage.
Specifications
| Virtual LAN features | |
|---|---|
| VLAN support | Yes |
| Number of VLANs | 4000 |
| Data transmission | |
| Number of VLANs | 4000 |
| Throughput | 190 Mpps |
| Packet buffer memory | 2 MB |
| MAC address table | 32000 entries |
| Switching capacity | 128 Gbit/s |
| Performance | |
| Packet buffer memory | 2 MB |
| Memory type | DDR3-SDRAM |
| Mean time between failures (MTBF) | 87660 h |
| Internal memory | 512 MB |
| Flash memory | 64 MB |
| Harmonized System (HS) code | 85176990 |
| Technical details | |
| Form factor | 1U |
| Product colour | White |
| Mean time between failures (MTBF) | 87660 h |
| Rack mounting | Yes |
| Management features | |
| Switch type | Managed |
| Switch layer | L2 |
| Ports & interfaces | |
| SFP+ module slots quantity | 4 |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Console port | RJ-45 |
| Network | |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Number of VLANs | 4000 |
| Link aggregation | Yes |
| 10G support | Yes |
| Security | |
| Access Control List (ACL) rules | 768 |
| Access Control List (ACL) | Yes |
| Certificates | |
| Certification | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 |
| Memory | |
| Packet buffer memory | 2 MB |
| Memory type | DDR3-SDRAM |
| Internal memory | 512 MB |
| Flash memory | 64 MB |
| Design | |
| Form factor | 1U |
| Product colour | White |
| Certification | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 |
| Rack mounting | Yes |
| Power | |
| Power consumption (max) | 26.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 24.8 W |
| Redundant power supply (RPS) support | No |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 89.683 BTU/h |
| Weight & dimensions | |
| Width | 17.3" (440 mm) |
| Depth | 10.2" (260 mm) |
| Height | 1.73" (44 mm) |
| Weight | 7.85 lbs (3.56 kg) |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
