V5925, PTZ, CMOS, 1/2.8, Autotracking, 1920x1080 FHD
Axis
Axis 01966-004 security camera Dome IP security camera Indoor 1920 x 1080 pixels Ceiling/wall
Part number:
01966-004
Sale price
$2,218.50
Regular price
$2,279.00
Save
$60.50
3%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- 3G-SDI and HDMI outputs; Camstreamer 3-month trial included; HDTV 1080p at 60 fps and 30x zoom; High-quality audio with XLR inputs; VISCA and VISCA over IP support
Description
AXIS V5925 combines excellent image quality with smooth PTZ control and broadcast-quality audio for professional webcasting. It’s compatible with VISCA joysticks and VISCA over IP, making it easy to integrate with your existing AV installations. Offering enhanced security features such as signed firmware and secure boot, it ensures the integrity and authenticity of the firmware. Furthermore, Axis Zipstream with H.264 and H.265 significantly reduces bandwidth and storage requirements without compromising image quality. NDI® compliant (license to be bought separately).Specifications
| Performance | |
|---|---|
| Preset points | Yes |
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 11 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian |
| Processor model | ARTPEC-7 |
| Fog proof | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor |
| Auto-tracking | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Design | |
| Fog proof | Yes |
| Form factor | Dome |
| Product colour | Black, White |
| Mounting type | Ceiling/wall |
| Housing material | Plastic |
| Camera | |
| Minimum illumination | 0.03 lx |
| Tilt angle range | -20 - 90° |
| Tilt speed | 90 °/sec |
| Pan range | -170 - 170° |
| Pan speed | 100 °/sec |
| Camera shutter speed | 1/10000 - 1 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 62° |
| Lens viewing angle, vertical | 37° |
| Progressive scan | Yes |
| Image sensor | |
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 1/2.8" |
| Number of sensors | 1 |
| Lens system | |
| Number of lenses | 1 |
| Maximum aperture number | 4.6 |
| Auto focus | Yes |
| Minimum aperture number | 1.4 |
| Zoom capability | Yes |
| Optical zoom | 30x |
| Digital zoom | 12x |
| Focal length range | 4.4 - 132 mm |
| Night vision | |
| Night vision | Yes |
| Video | |
| Image quality adjustment | Brightness, Saturation, Sharpness |
| Text caption overlay | Yes |
| Bit rate control | Variable Bit Rate (VBR) |
| Video compression formats | H.264, H.265 |
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 160 x 90, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| Frame rate | 60 fps |
| Video streaming | Yes |
| Audio | |
| Sample rate | 48 kHz |
| Audio system | 2-way |
| Audio formats supported | AAC, ADPCM, LPCM |
| Network | |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4/v6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSa , TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, SIP, LLDP, CDP, MQTT, Syslog, Link-Local address (ZeroConf), HDMI, 3G-SDI, VISCA |
| Storage | |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | SD, SDHC, SDXC |
| Internal memory | 1000 MB |
| Flash memory | 512 MB |
| Ports & interfaces | |
| Terminal block port | Yes |
| RS-232 ports | 1 |
| HDMI ports quantity | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Memory | |
| Internal memory | 1000 MB |
| Flash memory | 512 MB |
| Hard drive | |
| Built-in HDD | No |
| Technical details | |
| Video compression formats | H.264, H.265 |
| Type | IP security camera |
| Form factor | Dome |
| PTZ control | Yes |
| Placement supported | Indoor |
| Product colour | Black, White |
| Mounting type | Ceiling/wall |
| Auto-tracking | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Progressive scan | Yes |
| Warranty period | 5 year(s) |
| Security | |
| Alert notification type | |
| Video motion detection | Yes |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Pixel counter | Yes |
| Digest authentication | Yes |
| Material | |
| Housing material | Plastic |
| Power | |
| Power source type | DC |
| Power consumption (max) | 25 W |
| Power consumption (typical) | 14 W |
| DC-in jack | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 5.35" (136 mm) |
| Depth | 5.35" (136 mm) |
| Height | 7.09" (180 mm) |
| Weight | 3.31 lbs (1.5 kg) |
| Packaging content | |
| Number of cameras | 1 |
| Mounting kit | Yes |
| Manual | Yes |
| Cables included | DC |
| Other features | |
| Video compression formats | H.264, H.265 |
