15kVA / 13.5kW, 15 / 13.5 N+1, Hardwire (L-L-G)

Description

A Scalable Power Solution for Dynamic Demands
Pay as you grow design of the Liebert® APS simplifies the capacity planning process and provides budget flexibility.
FlexPower™ assemblies and battery modules allow for rapid deployment of capacity and runtime upgrades.

Built-in Redundancy and Modular Design provide Maximum Availability
Provide mission-critical availability and reduce costs while maintaining future flexibility with the Liebert APS uninterruptible power supply (UPS), a modular power solution for 5-20kVA N+1 applications.

Ultimate Flexibility and Serviceability
Your business depends on digital continuity, and along with the following benefits, the Liebert APS UPS ensures your critical IT applications are protected from power disruptions, fluctuations, and outages.

Reliability and Serviceability
Your business depends on the data center and the IT network to run. With the Liebert® APS UPS solution, you get peace of mind that your critical IT functions – and your business – will be available and running as expected through power disruptions, fluctuations and outages.

Specifications

Power
Output frequency	50/60 Hz
Output voltage regulation	±3%
Input power factor	0.99
Output power	13500 W
Input operation voltage (min)	200 V
Input operation voltage (max)	240 V
Output operation voltage (min)	100 V
Output operation voltage (max)	240 V
Efficiency	89.9%
Output power capacity	15 kVA
Input frequency	40/70 Hz
Performance
Power protection features	Overload
Features
Output frequency	50/60 Hz
Output voltage regulation	±3%
Input power factor	0.99
Output power	13500 W
Input operation voltage (min)	200 V
Input operation voltage (max)	240 V
Output operation voltage (min)	100 V
Output operation voltage (max)	240 V
Efficiency	89.9%
Power protection features	Overload
Output power capacity	15 kVA
Input frequency	40/70 Hz
Heat dissipation	5528 BTU/h
Battery
Battery voltage	1.67 V
Typical backup time at half load	14 min
Typical backup time at full load	5 min
Design
Product colour	Black
Safety	IEC/EN/AS 62040-1:2008, UL 1778 4th Ed & CSA 22.2 No. 107.1
Cooling type	Active
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Technical details
Output frequency	50/60 Hz
Compliance certificates	REACH, RoHS, WEEE
Certificates
Compliance certificates	REACH, RoHS, WEEE
Safety	IEC/EN/AS 62040-1:2008, UL 1778 4th Ed & CSA 22.2 No. 107.1
Cooling
Cooling type	Active
Safety regulation & standards
Safety	IEC/EN/AS 62040-1:2008, UL 1778 4th Ed & CSA 22.2 No. 107.1
Weight & dimensions
Weight	795 lbs (360.6 kg)
Width	17.3" (440 mm)
Height	41.7" (1060 mm)
Depth	31.5" (800 mm)
