HPE Aruba Networking AP-574 (US) 802.11ax 2x2/4x4 Dual Radio 6xNf Connectorized Outdoor AP, 2.4 GHz, 5 GHz, 10,1000,100 Mbit/s
Purpose-built to withstand extreme temperatures, persistent moisture and precipitation, and fully sealed to keep out airborne contaminants.
Weatherproof and temperature hardened, this series can handle temperatures ranging from -40˚C to +65˚C, including full sun deployments.
Enhanced wireless experience with HPE Aruba Networking ClientMatch technology removes sticky client issues by steering a client to the Access Point where it receives the best radio signal.
Supports Bluetooth 5 and Zigbee wireless protocols through an integrated IoT radio, and third-party expansion with an integrated USB port.
Target wake time (TWT) improves battery life of IoT devices.
HPE Aruba Networking Central Client Insights uses deep packet inspection to provide additional context and behavioral information that help verify devices are receiving proper policy enforcement and continuously monitor for rogue devices.
It offers stronger encryption and authentication with WPA3, protected credentials/keys storage for guest access with Enhanced Open, and user and IoT access policy enforcement firewalls.
It simplifies policy enforcement by using the Policy Enforcement Firewall (PEF) to encapsulate all traffic from the access point to the gateway (or mobility controller) for end-to-end encryption and inspection.
For enhanced device assurance, these access points include an installed Trusted Platform Module (TPM) for protected storage of credentials, keys, and boot code.
HPE
HPE Aruba Networking AP-574 (US) 802.11ax 2x2/4x4 Dual Radio 6xNf Connectorized Outdoor AP
Part number:
R4H13A
Sale price
$1,774.67
Regular price
$2,299.00
Save
$524.33
23%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Reasons To Buy
Reliable Outdoor Wi-Fi 6
HPE Aruba Networking 570 Series Outdoor Access Points support the Wi-Fi 6 standard, including features such as orthogonal frequency-division multiple access (OFDMA), bi-directional multi-user MIMO (MU-MIMO), and target wait time (TWT).Purpose-built to withstand extreme temperatures, persistent moisture and precipitation, and fully sealed to keep out airborne contaminants.
Weatherproof and temperature hardened, this series can handle temperatures ranging from -40˚C to +65˚C, including full sun deployments.
Enhanced wireless experience with HPE Aruba Networking ClientMatch technology removes sticky client issues by steering a client to the Access Point where it receives the best radio signal.
IoT Ready
HPE Aruba Networking 570 Series Outdoor access points can serve as IoT platforms that bolster network security and provide coverage for a range of IoT devices without the need for network overlays.Supports Bluetooth 5 and Zigbee wireless protocols through an integrated IoT radio, and third-party expansion with an integrated USB port.
Target wake time (TWT) improves battery life of IoT devices.
HPE Aruba Networking Central Client Insights uses deep packet inspection to provide additional context and behavioral information that help verify devices are receiving proper policy enforcement and continuously monitor for rogue devices.
Simple Access With Enhanced Security
The HPE Aruba Networking 570 Series Outdoor Access Points offer enhanced security with Dynamic Segmentation to remove the time consuming and error-prone task of managing complex and static VLANs, ACLs, and subnets by dynamically assigning policies and keeping traffic protected and separated.It offers stronger encryption and authentication with WPA3, protected credentials/keys storage for guest access with Enhanced Open, and user and IoT access policy enforcement firewalls.
It simplifies policy enforcement by using the Policy Enforcement Firewall (PEF) to encapsulate all traffic from the access point to the gateway (or mobility controller) for end-to-end encryption and inspection.
For enhanced device assurance, these access points include an installed Trusted Platform Module (TPM) for protected storage of credentials, keys, and boot code.
Description
HPE Aruba Networking AP-574 (US) 802.11ax 2x2/4x4 Dual Radio 6xNf Connectorized Outdoor AP. 2.4 GHz, 5 GHz, Ethernet LAN data rates: 10,1000,100 Mbit/s. Power over Ethernet (PoE). Product color: White. Power consumption (max): 32 WSpecifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Auto MDI/MDI-X | Yes |
| Frequency band | 2.4 - 5 GHz |
| Networking standards | IEEE 802.11ax |
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
| Certification | None |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Wireless LAN features | |
| Frequency band | 2.4 - 5 GHz |
| Network | |
| Networking standards | IEEE 802.11ax |
| Features | |
| 6 GHz | No |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Auto MDI/MDI-X | Yes |
| Frequency band | 2.4 - 5 GHz |
| Networking standards | IEEE 802.11ax |
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Maximal-Ratio Combining (MRC) | Yes |
| Cyclic Shift Diversity (CSD) | Yes |
| Cyclic Delay Diversity (CDD) | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| BeamForming | Yes |
| Power | |
| Power consumption (max) | 32 W |
| Power over Ethernet (PoE) | Yes |
| Design | |
| Placement | Pole, Wall |
| Product colour | White |
| Certification | None |
| Antenna | |
| Antenna type | Internal |
| Antenna connector type | RP-SMA |
| Antenna direction type | Omni-directional |
| Technical details | |
| Compliance certificates | Federal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD) |
| Certificates | |
| Certification | None |
| Compliance certificates | Federal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD) |
| Software | |
| Maximal-Ratio Combining (MRC) | Yes |
| Cyclic Shift Diversity (CSD) | Yes |
| Cyclic Delay Diversity (CDD) | Yes |
| Weight & dimensions | |
| Width | 9.06" (230 mm) |
| Depth | 9.45" (240 mm) |
| Weight | 5.29 lbs (2.4 kg) |
| Height | 7.48" (190 mm) |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 93% |
| Operating temperature (T-T) | -40 - 65 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
