1 x 2.5-inch SATA 6Gbps SSD, 69.87 x 21.78 x 14.5 mm, 0.02 kg, 4 psc
2.5-inch 6Gbps SAS to SATA drive adapter (Designed for dual-controller all-flash ES2486dc NAS)
The QDA-SA3 adapter is designed for QNAP’s dual-controller all-flash array Enterprise ZFS NAS (ES2486dc) and allows the usage of a SATA 6Gbps drive in a 2.5-inch SAS 12Gbps/6Gbps drive bay — providing the ability to expand storage capacity with cost-effective SATA drives.
SAS dual-port advantage for fault tolerance
SAS features dual porting for redundancy, eliminating single points of failure and allowing for higher reliability and performance. By installing a SATA drive with the QDA-SA3 into a dual-controller all-flash Enterprise ZFS NAS, the SATA drive can share these SAS dual-port advantages to ensure a high-availability, fault tolerant enterprise storage environment.
Designed for all-flash Enterprise ZFS NAS
The QDA-SA3 can be easily installed in the 2.5-inch disk tray of an all-flash array Enterprise ZFS NAS (ES2486dc disk tray model: TRAY-25-NK-BLK04).
QNAP
QNAP QDA-SA3 interface cards/adapter Internal SATA
Part number:
QDA-SA3-4PCS
$216.92
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Supports 2.5-inch SATA HDD/SSD
- Up to 6Gb/s file transfer speeds
- The installed SATA drive can share SAS dual-port advantages for higher reliability
Description
QDA-SA32.5-inch 6Gbps SAS to SATA drive adapter (Designed for dual-controller all-flash ES2486dc NAS)
The QDA-SA3 adapter is designed for QNAP’s dual-controller all-flash array Enterprise ZFS NAS (ES2486dc) and allows the usage of a SATA 6Gbps drive in a 2.5-inch SAS 12Gbps/6Gbps drive bay — providing the ability to expand storage capacity with cost-effective SATA drives.
SAS dual-port advantage for fault tolerance
SAS features dual porting for redundancy, eliminating single points of failure and allowing for higher reliability and performance. By installing a SATA drive with the QDA-SA3 into a dual-controller all-flash Enterprise ZFS NAS, the SATA drive can share these SAS dual-port advantages to ensure a high-availability, fault tolerant enterprise storage environment.
Designed for all-flash Enterprise ZFS NAS
The QDA-SA3 can be easily installed in the 2.5-inch disk tray of an all-flash array Enterprise ZFS NAS (ES2486dc disk tray model: TRAY-25-NK-BLK04).
Specifications
| Ports & interfaces | |
|---|---|
| Internal | Yes |
| Output interface | SATA |
| SATA revision | 3.0 |
| Internal SATA ports quantity | 1 |
| Host interface | SAS |
| Technical details | |
| Data transfer rate (max) | 6 Gbit/s |
| Performance | |
| Data transfer rate (max) | 6 Gbit/s |
| Product colour | Black, Gray |
| Harmonized System (HS) code | 84733020 |
| Colour | |
| Product colour | Black, Gray |
| Design | |
| Internal | Yes |
| Product colour | Black, Gray |
| Features | |
| Data transfer rate (max) | 6 Gbit/s |
| Harmonized System (HS) code | 84733020 |
| Weight & dimensions | |
| Width | 2.75" (69.9 mm) |
| Depth | 0.857" (21.8 mm) |
| Height | 0.571" (14.5 mm) |
| Weight | 0.705 oz (20 g) |
| Packaging data | |
| Quick installation guide | Yes |
| Quantity | 4 |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
| Packaging content | |
| Quick installation guide | Yes |
| Quantity | 4 |
