Intel Xeon E-2236 (12MB Cache, 3.4GHz), 8GB DDR4-SDRAM (2666MHz), LAN (Broadcom BCM5720), 450W, No OS
The Lenovo ThinkSystem SR250 is a single-processor rack server that integrates power, reliability, flexibility, and security in a compact 1U form factor suited for the small-to-medium business.
The SR250 boasts a high price-performance ratio with a combination of high-processing capability and dependability with next-generation Intel® Xeon® E-2200 processors and support for an array of storage configurations.
It provides the flexibility to handle workloads including web serving, virtualization, entry-cloud and data-analytics applications, while integrated Intel Software Guard Extensions (SGX) secure the SR250 for blockchain applications.
Flexible and scalable
The ThinkSystem SR250 adapts to multiple environments and workloads in which a shorter-depth rack accommodates space-constrained environments. Also, lightning-fast TruDDR4 memory, GPU support, and an array of storage options, including low-latency NVMe drives, afford serious storage and workload flexibility.
Superb I/O capability via multiple network interface ports and a dedicated management port handle heavy network communications and enable faster data transmission.
The SR250 also features the option for either a fixed or redundant power supply unit depending on the data center deployment model. These options allow users to configure the SR250 to specifications appropriate for their distinct enterprise use and optimize server utility for future scalability.
Simple management
The ThinkSystem SR250 features the Lenovo XClarity Controller, the embedded management engine in all ThinkSystem servers that is designed to standardize, simplify, and automate foundation server management tasks.
Lenovo XClarity Administrator is a virtualized application that centrally manages ThinkSystem servers, storage, and networking, which can reduce provisioning time up to 95 percent versus manual operation. And running XClarity Integrator helps you streamline IT management, speed provisioning, and contain costs by seamlessly integrating XClarity into an existing IT environment.
Lenovo
Lenovo ThinkSystem SR250 server Rack (1U) Intel Xeon E E-2236 3.4 GHz 8 GB DDR4-SDRAM 450 W
Part number:
7Y51A04RNA
$1,530.35
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- No OS
- Intel Xeon E-2236 (12MB Cache, 3.4GHz)
- 8GB (2666MHz) DDR4-SDRAM (1 x 8)
Description
Powerful and secureThe Lenovo ThinkSystem SR250 is a single-processor rack server that integrates power, reliability, flexibility, and security in a compact 1U form factor suited for the small-to-medium business.
The SR250 boasts a high price-performance ratio with a combination of high-processing capability and dependability with next-generation Intel® Xeon® E-2200 processors and support for an array of storage configurations.
It provides the flexibility to handle workloads including web serving, virtualization, entry-cloud and data-analytics applications, while integrated Intel Software Guard Extensions (SGX) secure the SR250 for blockchain applications.
Flexible and scalable
The ThinkSystem SR250 adapts to multiple environments and workloads in which a shorter-depth rack accommodates space-constrained environments. Also, lightning-fast TruDDR4 memory, GPU support, and an array of storage options, including low-latency NVMe drives, afford serious storage and workload flexibility.
Superb I/O capability via multiple network interface ports and a dedicated management port handle heavy network communications and enable faster data transmission.
The SR250 also features the option for either a fixed or redundant power supply unit depending on the data center deployment model. These options allow users to configure the SR250 to specifications appropriate for their distinct enterprise use and optimize server utility for future scalability.
Simple management
The ThinkSystem SR250 features the Lenovo XClarity Controller, the embedded management engine in all ThinkSystem servers that is designed to standardize, simplify, and automate foundation server management tasks.
Lenovo XClarity Administrator is a virtualized application that centrally manages ThinkSystem servers, storage, and networking, which can reduce provisioning time up to 95 percent versus manual operation. And running XClarity Integrator helps you streamline IT management, speed provisioning, and contain costs by seamlessly integrating XClarity into an existing IT environment.
Specifications
| Processor | |
|---|---|
| Tjunction | 100 °C |
| Thermal Monitoring Technologies | Yes |
| Thermal Design Power (TDP) | 80 W |
| Tcase | 73 °C |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| Scalability | 1S |
| Processor threads | 12 |
| Processor package size | 37.5 x 37.5 mm |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Coffee Lake |
| PCI Express configurations | 1x16, 2x8, 1x8+2x4 |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Maximum number of PCI Express lanes | 16 |
| Maximum internal memory supported by processor | 128 GB |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| Processor cache | 12 MB |
| Processor frequency | 3.4 GHz |
| Number of processors installed | 1 |
| Processor model | E-2236 |
| Processor boost frequency | 4.8 GHz |
| Processor socket | LGA 1151 (Socket H4) |
| Processor cores | 6 |
| Processor manufacturer | Intel |
| Motherboard chipset | Intel C246 |
| Maximum number of SMP processors | 1 |
| Processor family | Intel Xeon E |
| Memory | |
| Internal memory | 8 GB |
| Memory layout (slots x size) | 1 x 8 GB |
| Memory slots | 4x DIMM |
| Memory clock speed | 2666 MHz |
| Maximum internal memory | 128 GB |
| Internal memory type | DDR4-SDRAM |
| ECC | Yes |
| Storage | |
| Hot-swap | Yes |
| RAID support | No |
| Optical drive type | No |
| Internal drive bays | 4 |
| Graphics | |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card dynamic frequency (max) | 1200 MHz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card base frequency | 350 MHz |
| Number of displays supported (on-board graphics) | 3 |
| Maximum on-board graphics card memory | 128 GB |
| On-board graphics card ID | 0x3E96 |
| Maximum graphics card memory | 16 MB |
| Network | |
| LAN controller | Broadcom BCM5720 |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 2 |
| USB 2.0 ports quantity | 1 |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 3 |
| Expansion slots | |
| PCI Express x4 (Gen 3.x) slots | 1 |
| PCI Express slots version | 3.0 |
| PCI Express x8 (Gen 3.x) slots | 2 |
| Optical drive | |
| Optical drive type | No |
| Design | |
| Rack rails | Yes |
| Rack mounting | Yes |
| Optical drive type | No |
| Chassis type | Rack (1U) |
| Product colour | Black |
| Performance | |
| Compatible operating systems | Microsoft Windows Server 2016/2019, Red Hat Enterprise Linux 7/8, SUSE Linux Enterprise Server 12/15, VMware vSphere (ESXi) 6.5/6.7/7.0 |
| Performance management | XClarity Enterprise |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Operating system installed | No |
| Software | |
| Compatible operating systems | Microsoft Windows Server 2016/2019, Red Hat Enterprise Linux 7/8, SUSE Linux Enterprise Server 12/15, VMware vSphere (ESXi) 6.5/6.7/7.0 |
| Operating system installed | No |
| Processor special features | |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® OS Guard | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® Secure Key | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Clear Video Technology | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 191043 |
| CPU configuration (max) | 1 |
| Power | |
| Number of main power supplies | 1 |
| Number of redundant power supplies supported | 2 |
| Redundant power supply (RPS) support | Yes |
| Power supply | 450 W |
| Technical details | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Rack rails | Yes |
| Rack mounting | Yes |
| Ethernet interface type | Gigabit Ethernet |
| CPU configuration (max) | 1 |
| Chassis type | Rack (1U) |
| PCI Express x8 (Gen 3.x) slots | 2 |
| Management features | |
| Performance management | XClarity Enterprise |
| Weight & dimensions | |
| Width | 17.1" (434 mm) |
| Weight | 20.1 lbs (9.1 kg) |
| Height | 1.69" (43 mm) |
| Depth | 19.6" (498 mm) |
| Other features | |
| CPU configuration (max) | 1 |
