16-Port Industrial Gigabit PoE+ DIN-Rail Switch
Trendnet
Trendnet TI-PG162 network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Part number:
TI-PG162
Sale price
$453.11
Regular price
$552.91
Save
$99.80
18%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- 14 x Gigabit ports
- 2 x Gigabit SFP slots
- 32Gbps switching capacity
- Hardened IP30 rated metal switch
- Includes DIN-Rail mount and wall mount brackets
- Wide operating temperature range of -40° – 75°C (-40° – 167°F)
- Multiple power inputs provide redundant power with overload current protection
- Alarm output triggered by power failure
Description
TRENDnet's Industrial Gigabit PoE+ DIN-Rail Switches provide network connectivity in rugged environments, while saving you on installation costs and setup time using Power over Ethernet technology. The Industrial Gigabit PoE+ DIN-Rail Switches each feature a rugged IP30 rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating in both high and low temperatures for industrial environments within -40° – 75° C (-40° – 167° F). Our hardened industrial PoE+ switch models feature copper Gigabit PoE+ ports for high-speed device connections, and SFP slots that support 1000Base-FX modules for long distance fiber networking applications.Specifications
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Ports & interfaces | |
| SFP module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 14 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Full duplex | Yes |
| 10G support | No |
| Data transmission | |
| Jumbo frames | 9000 |
| Packet buffer memory | 0.5 MB |
| MAC address table | 8000 entries |
| Switching capacity | 32 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 23.8 Mpps |
| Design | |
| Wall mountable | Yes |
| International Protection (IP) code | IP30 |
| DIN rail mounting | Yes |
| Product colour | Black |
| LED indicators | Yes |
| Housing material | Metal |
| Rack mounting | No |
| Certification | CE FCC MET IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 |
| Performance | |
| Mean time between failures (MTBF) | 514167 h |
| Packet buffer memory | 0.5 MB |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Power consumption (max) | 13 W |
| Power supply included | No |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 2 A |
| DC input voltage | 48 - 56 V |
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 14 |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Width | 4.72" (120 mm) |
| Depth | 6.1" (155 mm) |
| Height | 1.89" (48 mm) |
| Weight | 18.9 oz (536 g) |
| Packaging content | |
| Quick start guide | Yes |
| Technical details | |
| Product colour | Black |
| Mean time between failures (MTBF) | 514167 h |
| Housing material | Metal |
| Rack mounting | No |
| Memory | |
| Packet buffer memory | 0.5 MB |
| Certificates | |
| Certification | CE FCC MET IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 |
| Indication | |
| LED indicators | Yes |
| Packaging data | |
| Quick start guide | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
