Decrease quantity Increase quantity Add to cart Added

5 M, 0.15 Lux, 30fps, Micro SD, PoE, MJPEG, 2592 x 1944

Description

Max. 5Megapixel (2592 x 1944) resolution
3.2~10mm(3.1x) motorized varifocal lens
0.15Lux (Color), 0Lux (B/W, IR LED on)
Max. 30fps@5MP (H.265 / H.264)
H.265, H.264, MJPEG codec support, Multiple streaming
Day & Night, WDR (120dB)
Tampering, Motion detection, Defocus detection
Micro SD / SDHC / SDXC memory slot (Max. 128GB)
Hallway view, WiseStream II support
IR Viewable length 20m, PoE

Specifications

Performance
Languages support	Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish
Type	IP security camera
Connectivity technology	Wired
Placement supported	Outdoor
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Alarm input/output	Yes
Design
Form factor	Dome
Product colour	White
Mounting type	Ceiling
Housing material	Aluminum, Plastic
Camera
Adjustment shutter speed	Manual
Minimum illumination	0.15 lx
Tilt angle range	0 - 67°
Pan range	0 - 350°
White balance	ATW, AWC, Indoor, Manual, Outdoor
Camera shutter type	Electronic
Lens viewing angle, horizontal	100.3°
Lens viewing angle, vertical	72.3°
Lens viewing angle, diagonal	133.1°
Progressive scan	Yes
Image sensor
Number of effective pixels (H x V)	2592 x 1944 pixels
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/2.8"
Lens system
Maximum aperture number	1.6
Fixed focus	Yes
Focal length range	3.2 - 10 mm
Night vision
Night vision	Yes
Night vision distance	20 m
LED type	IR
Video
Noise reduction	Yes
Flip & mirror	Yes
Gain control type	Manual
Back Light Compensation (BLC)	Yes
Video compression formats	H.264, H.265, M-JPEG
Maximum resolution	2592 x 1944 pixels
Supported graphics resolutions	640 x 360, 640 x 480 (VGA), 720 x 480, 768 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 960, 1920 x 1080 (HD 1080), 2592 x 1944
Video streaming	Yes
Total megapixels	5 MP
Network
Bluetooth	No
Ethernet interface type	10 Gigabit Ethernet, 100 Gigabit Ethernet
Networking standards	IEEE 802.1x
Quality of Service (QoS) support	Yes
Number of users	6 user(s)
Streaming method	Multicast, Unicast
Ethernet LAN	Yes
Wi-Fi	No
Supported network protocols	IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
Storage
Maximum memory card size	128 GB
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired
Technical details
Video compression formats	H.264, H.265, M-JPEG
Type	IP security camera
Form factor	Dome
Placement supported	Outdoor
Product colour	White
Mounting type	Ceiling
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Alarm input/output	Yes
Progressive scan	Yes
Security
Alert notification type	E-mail
Video motion detection	Yes
IP address filtering	Yes
Active tampering alarm	Yes
Material
Housing material	Aluminum, Plastic
Software
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Power
Power source type	PoE
Power consumption (max)	8.9 W
Power consumption (typical)	6.6 W
Operational conditions
Operating temperature (T-T)	-30 - 55 °C
Storage temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 90%
System requirements
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Weight & dimensions
Height	4.02" (102 mm)
Diameter	4.72" (12 cm)
Weight	15.2 oz (430 g)
Packaging content
Number of cameras	1
Other features
Video compression formats	H.264, H.265, M-JPEG
