10000VA /10000W, 176-280V, Hard-wire

Description

10kVA, 10kW, 208V In, 120V/208V Out

Specifications

Power
Output power	10000 W
Input operation voltage (min)	176 V
Input operation voltage (max)	280 V
Output operation voltage (min)	120 V
Output operation voltage (max)	208 V
Output power capacity	10 kVA
Input frequency	40 - 70 Hz
Performance
UPS topology	Double-conversion (Online)
Waveform	Sine
Power protection features	Overload
Noise level	50 dB
Features
UPS topology	Double-conversion (Online)
Waveform	Sine
Output power	10000 W
Input operation voltage (min)	176 V
Input operation voltage (max)	280 V
Output operation voltage (min)	120 V
Output operation voltage (max)	208 V
Power protection features	Overload
Noise level	50 dB
Output power capacity	10 kVA
Input frequency	40 - 70 Hz
Battery
Battery technology	Sealed Lead Acid (VRLA)
Typical backup time at half load	12.5 min
Typical backup time at full load	4.5 min
Design
Rack capacity	5U
Form factor	Rackmount/Tower
Product colour	Black
Safety	UL1778, c-UL listed CSA 22.2 No 107.3
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 40 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Safety regulation & standards
Safety	UL1778, c-UL listed CSA 22.2 No 107.3
Weight & dimensions
Weight	224.9 lbs (102 kg)
Width	16.9" (430 mm)
Height	10.3" (261 mm)
Depth	25.6" (650 mm)
Certificates
Safety	UL1778, c-UL listed CSA 22.2 No 107.3
