Vertiv VR Rack - 42U Server Rack Enclosure| 2000x600x1100mm (HxWxD)| 19-inch rack cabinet (VR3100)
Standardize your deployments around the world and bring them online faster with the Vertiv™ VR rack. The Vertiv VR supports a wide variety of equipment, including: servers, storage, switches, routers, PDUs, UPSs, console port servers and KVM switches.
The Vertiv VR is delivered ready for high density environments to serve your mission critical needs — even as they evolve and change. This rack gives you the flexibility you need with easy installation.
Vertiv
Vertiv VR Rack VR3100 rack cabinet 42U Freestanding rack Black, Transparent
Part number:
VR3100
Sale price
$1,997.31
Regular price
$3,098.00
Save
$1,100.69
36%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- 42U frame height that will allow access through standard doors on four swivel casters
- Frame capable of supporting up to 1360kg Static, 1022kg Dynamic
- Two dual purpose full height depth adjustable PDU / Cable management brackets for tool-less mounting of PDUs and integrated cable tie off positions
- Low profile casters and leveling feet
- High Density Cable Entry Top Panel Removable openings for cable entry — ready for front / rear cabling. Can accommodate over 2000 Cat 6 cables
- Single and split 77% perforated doors providing maximum airflow. Lift off hinges for easy removal, and field reversibility
Description
Rapid Deployments Everywhere You OperateStandardize your deployments around the world and bring them online faster with the Vertiv™ VR rack. The Vertiv VR supports a wide variety of equipment, including: servers, storage, switches, routers, PDUs, UPSs, console port servers and KVM switches.
The Vertiv VR is delivered ready for high density environments to serve your mission critical needs — even as they evolve and change. This rack gives you the flexibility you need with easy installation.
Specifications
| Features | |
|---|---|
| Size (imperial) | 19" |
| Key lock | Yes |
| Rack capacity | 42U |
| Maximum weight capacity (rolling) | 2253.1 lbs (1022 kg) |
| Removable back door | Yes |
| Removable front door | Yes |
| Removable side panels | Yes |
| Back door construction | Perforated |
| Front door construction | Perforated |
| Side panel construction | Steel |
| Cable management | Yes |
| Mounting hole shape | Square |
| Adjustable feet | Yes |
| Feet adjustment | 2.13" (5.4 cm) |
| Back door key lock | Yes |
| Front door key lock | Yes |
| Side panel key lock | Yes |
| Type | Freestanding rack |
| Side panels included | Yes |
| Maximum weight capacity | 3000.5 lbs (1361 kg) |
| Material | Metal |
| Product colour | Black, Transparent |
| Certification | EIA 310E, UL2416, REACH |
| Weight & dimensions | |
| Package volume | 2139850 cm³ |
| Package depth | 54.5" (1385 mm) |
| Package width | 28.5" (724 mm) |
| Package height | 84" (2134 mm) |
| Package weight | 359.4 lbs (163 kg) |
| Width | 23.6" (600 mm) |
| Depth | 43.3" (1100 mm) |
| Height | 78.7" (2000 mm) |
| Weight | 280 lbs (127 kg) |
| Size (imperial) | 19" |
| Maximum weight capacity | 3000.5 lbs (1361 kg) |
| Packaging content | |
| Nuts included | Yes |
| Number of nuts | 50 |
| Screws included | Yes |
| Number of screws | 50 |
| Mounting hardware included in set | 50 each M6 cage nuts and screws, Cage nut installation tool, edge protection for top panel cable entry, T30 extension driver and Keys |
| Packaging data | |
| Nuts included | Yes |
| Number of nuts | 50 |
| Package volume | 2139850 cm³ |
| Package depth | 54.5" (1385 mm) |
| Package width | 28.5" (724 mm) |
| Package height | 84" (2134 mm) |
| Package weight | 359.4 lbs (163 kg) |
| Screws included | Yes |
| Number of screws | 50 |
| Mounting hardware included in set | 50 each M6 cage nuts and screws, Cage nut installation tool, edge protection for top panel cable entry, T30 extension driver and Keys |
| Technical details | |
| Package width | 28.5" (724 mm) |
| Package height | 84" (2134 mm) |
| Type | Freestanding rack |
| Size (imperial) | 19" |
| Side panels included | Yes |
| Harmonized System (HS) code | 85381000 |
| Compliance certificates | RoHS |
| Rack capacity | 42U |
| Colour | |
| Product colour | Black, Transparent |
| Certificates | |
| Certification | EIA 310E, UL2416, REACH |
| Material | |
| Material | Metal |
| Logistics data | |
| Harmonized System (HS) code | 85381000 |
