4-Port USB 2.0 CAT 5 Extender (up to 50m)
The UCE3250 transmits data through signal packages with better compatibility and preserves the integrity of the data over long distances. The power supply at the remote UCE3250 unit helps provide sufficient power to any type of USB device, such as flash drives, keyboards, mice, webcams, scanners, or printers, etc.
With its durable metal housing, this high-quality USB extender provides a fast and flexible solution for industrial applications. In addition, the compact size and integrated wall mounting enables space-saving installation.
ATEN
ATEN UCE3250 interface cards/adapter
Part number:
UCE3250
$101.09
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- High-Speed USB 2.0 compliant with a data transfer rate of up to 480 Mbps
- Extension distance of up to 50m over a Cat 5/5e/6 cable
- Receives up to 4 USB peripherals of all types – flash drives, keyboards, mice, webcams, scanners, printers and more
- Metal mechanical with wall mount design supports industrial deployment
- Supports Windows®, OS X®, and Linux®
- Plug- and- play
Description
The UCE3250 4-port USB 2.0 Cat 5 Extender is a two-unit device that serves as a USB hub and a USB extender. The UCE3250 unit can connect as many as 4 USB peripherals from up to 50 meters away from your computer over a Cat 5 / 5e / 6 Ethernet cable.The UCE3250 transmits data through signal packages with better compatibility and preserves the integrity of the data over long distances. The power supply at the remote UCE3250 unit helps provide sufficient power to any type of USB device, such as flash drives, keyboards, mice, webcams, scanners, or printers, etc.
With its durable metal housing, this high-quality USB extender provides a fast and flexible solution for industrial applications. In addition, the compact size and integrated wall mounting enables space-saving installation.
Specifications
| Technical details | |
|---|---|
| Plug and Play | Yes |
| Cable length | 1968.5" (50 m) |
| Quantity per pack | 1 pc(s) |
| Compliance certificates | RoHS |
| Performance | |
| Port multiplier | Yes |
| Plug and Play | Yes |
| Product colour | Black |
| Harmonized System (HS) code | 84733020 |
| Colour | |
| Product colour | Black |
| Ports & interfaces | |
| Port multiplier | Yes |
| Design | |
| Product colour | Black |
| LED indicators | Activity |
| Features | |
| Plug and Play | Yes |
| Harmonized System (HS) code | 84733020 |
| Power | |
| USB powered | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Weight & dimensions | |
| Width | 2.49" (63.3 mm) |
| Depth | 4.35" (110.4 mm) |
| Height | 0.949" (24.1 mm) |
| Weight | 5.64 oz (160 g) |
| Packaging data | |
| Manual | Yes |
| Cables included | USB |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
| Quantity per pack | 1 pc(s) |
| Other features | |
| Cable length | 1968.5" (50 m) |
| Relative humidity | 0 - 80% |
| Packaging content | |
| Manual | Yes |
| Cables included | USB |
