NSa 3650, , 3.75 Gbps, IPS 1.8 Gbps, 8 x 2.5GbE SFP, 2 x 10GbE SFP+, 12 x 1GbE, 4 x 2.5GbE, 32 GB Storage, + Advanced Edition (1 Year)
SonicWall
SonicWall NSa 3650 + Advanced Edition (1 Year) hardware firewall 1U 3.75 Gbit/s
Part number:
01-SSC-4081
Sale price
$5,943.96
Regular price
$6,840.00
Save
$896.04
13%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- Superior threat prevention
- High-performance architecture
- Network control and flexibility
- 802.11ac Wave 2 wireless
- Broad mobility support
- High port density
Description
The SonicWall Network Security appliance (NSa) Mid-Range Firewall series consolidates automated advanced threat prevention technologies in a mid-range next-generation firewall platform. Built on a multi-core hardware architecture featuring 10-GbE and 2.5-GbE interfaces, the NSa series scales to meet the performance demands of mid-sized networks, branch offices and distributed enterprises. NSa series firewalls feature cloud-based and on-box capabilities such as TLS/SSL decryption and inspection, application intelligence and control, Secure SD-WAN, real-time visualization and WLAN management.Specifications
| Data transmission | |
|---|---|
| IPSec VPN throughput | 1.5 Gbit/s |
| Maximum connections (DPI) | 750000 |
| Maximum connections (SPI) | 2000000 |
| Firewall (IMIX) throughput | 0.9 Gbit/s |
| VPN (IMIX) throughput | 900 Mbit/s |
| Current connections (proxy) | 14000 |
| VoIP | Yes |
| Firewall throughput | 3.75 Gbit/s |
| VPN throughput | 1.5 Gbit/s |
| Firewall throughput | 3750 Mbit/s |
| VPN throughput | 1500 Mbit/s |
| Performance | |
| Processor cores | 4 |
| Mean time between failures (MTBF) | 156681 h |
| Concurrent users | 50000 user(s) |
| Compatible operating systems | SonicOS 6.5.x |
| Certification | ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL, USGv6, CsFC |
| Network | |
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Networking standards | IEEE 802.1p, IEEE 802.3 |
| VPN tunnels quantity | 3000 |
| Number of users | 50000 user(s) |
| Quality of Service (QoS) support | Yes |
| Port forwarding | Yes |
| Number of VLANs | 256 |
| Multicast support | Yes |
| DHCP server | Yes |
| DHCP client | Yes |
| Number of LAN Access Points (max) | 96 |
| Security | |
| Security algorithms | 3DES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1 |
| Deep Packet Inspection (DPI) | Yes |
| Protocols | |
| Management protocols | SNMP v2/v3 |
| Supported network protocols | TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP |
| Routing protocols | BGP, OSPF, RIP, RIP-1, RIP-2 |
| Management features | |
| LED indicators | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| SFP+ module slots quantity | 2 |
| SFP module slots quantity | 8 |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 16 |
| Number of expansion slots | 1 |
| Console port | RJ-45 |
| Remote management port | RJ-45 (Gigabit) |
| Number of console ports | 1 |
| Storage | |
| Storage media type | Flash |
| Total storage capacity | 32 GB |
| Design | |
| Rack mounting | Yes |
| Form factor | 1U |
| Number of fans | 2 fan(s) |
| Built-in fan | Yes |
| Power | |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Redundant power supply (RPS) support | Yes |
| Power supply | 120 W |
| Power consumption (max) | 46 W |
| Certificates | |
| Certification | ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL, USGv6, CsFC |
| Operational conditions | |
| Operating temperature (T-T) | 32 - 105 °C |
| Storage temperature (T-T) | -40 - 158 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Weight | 11.7 lbs (5.3 kg) |
| Width | 16.9" (429.3 mm) |
| Depth | 12.8" (325.1 mm) |
| Height | 1.8" (45.7 mm) |
| Technical details | |
| Rack mounting | Yes |
| Form factor | 1U |
| Concurrent users | 50000 user(s) |
| Harmonized System (HS) code | 85176990 |
| Hard drive | |
| Storage media type | Flash |
| Total storage capacity | 32 GB |
| Endurance | |
| Mean time between failures (MTBF) | 156681 h |
| System requirements | |
| Compatible operating systems | SonicOS 6.5.x |
| Other features | |
| Firewall throughput | 3750 Mbit/s |
| VPN throughput | 1500 Mbit/s |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
