5-Port Gigabit EdgeSmart Switch
Trendnet
Trendnet TEG-S50ES network switch Managed Gigabit Ethernet (10/100/1000) Black
Part number:
TEG-S50ES
Sale price
$34.65
Regular price
$34.99
Save
$0.34
1%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- 5 x Gigabit ports
- Easy to use web-based management interface
- Supports static link aggregation, RSTP, VLAN, QoS, and IGMP Snooping
- Voice VLAN for VoIP applications
- Bandwidth control per port
- 10Gbps switching capacity
- IEEE 802.1p CoS with queue scheduling support
- Compact fanless design
- Wall mountable metal housing
- NDAA / TAA compliant (U.S. and Canada only)
Description
TRENDnet's 5-Port Gigabit EdgeSmart Switch, model TEG-S50ES, is a cost-effective switch solution for high-speed gigabit applications. This 5-port smart switch features the most commonly used managed switch features, reducing unnecessary switch complexity. The web-based management interface offers features for traffic control, RSTP, VLAN, QoS, access control, static link aggregation, and monitoring. TRENDnet's TEG-S50ES allows for simple network integration into your SMB network.Specifications
| Management features | |
|---|---|
| Reset button | Yes |
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | DC-in jack |
| Network | |
| Networking standards | IEEE 802.11d, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Full duplex | Yes |
| VLAN support | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| 10G support | No |
| Virtual LAN features | Private VLAN, Voice VLAN, Tagged VLAN, Port-based VLAN |
| IGMP snooping | Yes |
| Data transmission | |
| Jumbo frames | 9000 |
| MAC address table | 2000 entries |
| Switching capacity | 10 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 7.44 Mpps |
| Security | |
| Security algorithms | SNMP, SNMPv3 |
| IGMP snooping | Yes |
| Queue scheduling algorithms | SP, WFQ |
| Design | |
| Reset button | Yes |
| Product colour | Black |
| LED indicators | Yes |
| Housing material | Metal |
| Rack mounting | No |
| Certification | CE, FCC |
| Performance | |
| Buffer size | 125 KB |
| Mean time between failures (MTBF) | 1633047 h |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Output voltage | 5 V |
| Output current | 1 A |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 3.42 W |
| Input current | 0.2 A |
| Power connector | DC-in jack |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Virtual LAN features | |
| VLAN support | Yes |
| Virtual LAN features | Private VLAN, Voice VLAN, Tagged VLAN, Port-based VLAN |
| Weight & dimensions | |
| Width | 3.96" (100.5 mm) |
| Depth | 3.23" (82 mm) |
| Height | 1.1" (28 mm) |
| Weight | 7.9 oz (224 g) |
| Packaging content | |
| Quick start guide | Yes |
| AC adapter included | Yes |
| Packaging data | |
| AC adapter included | Yes |
| Quick start guide | Yes |
| Technical details | |
| Product colour | Black |
| Mean time between failures (MTBF) | 1633047 h |
| Housing material | Metal |
| Rack mounting | No |
| Certificates | |
| Certification | CE, FCC |
| Indication | |
| LED indicators | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
