1000BASE-T to SFP Fiber Media Converter
Trendnet
Trendnet TFC-GSFP network media converter 2000 Mbit/s Multi-mode, Single-mode Black
Part number:
TFC-GSFP
Sale price
$40.71
Regular price
$50.26
Save
$9.55
19%
OFF
Shipping time varies based your on location.
Enjoy Free Shipping on orders over $2000 USD
Key Features
- 1 x 1000BASE-T RJ-45 port
- 1 x 1000BASE-SX/LX SFP slot
- SFP slot accommodates multimode or single-mode modules
- Auto-MDIX 1000BASE-T RJ-45 port supports full-duplex mode
- Not compatible with TFC-1600
- NDAA / TAA compliant (U.S. and Canada only)
Description
This compact fiber media converter transforms 1000BASE-T (Copper Gigabit) media to 1000BASE-SX/LX (Fiber) SFP media and vice versa. The 1000BASE-T RJ-45 port supports a full-duplex Gigabit connection at wire speed. The SFP slot supports both multimode (SX) or single-mode (LX) SFP modules.Specifications
| Network | |
|---|---|
| Flow control support | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Fiber ethernet cabling technology | 1000BASE‑LX, 1000BASE‑SX |
| Converter input interface | 1000Base-T |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Duplex system | Full, Half |
| Converter output interface | 1000Base-LX, 1000Base-SX |
| Auto MDI/MDI-X | Yes |
| Maximum data transfer rate | 2000 Mbit/s |
| Fiber optic connector | SFP |
| Performance | |
| Fiber mode structure | Multi-mode, Single-mode |
| Flow control support | Yes |
| Features | |
| LED indicators | Yes |
| Product colour | Black |
| Internal | No |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SFP |
| DC-in jack | Yes |
| Power | |
| Power consumption (max) | 5 W |
| Input voltage | 110 - 240 V |
| Output voltage | 5 V |
| Output current | 1 A |
| AC input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Width | 2.95" (75 mm) |
| Depth | 2.36" (60 mm) |
| Weight | 5.5 oz (156 g) |
| Height | 0.472" (12 mm) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Packaging content | |
| Quick installation guide | Yes |
| AC adapter included | Yes |
| Technical details | |
| Fiber mode structure | Multi-mode, Single-mode |
| Internal | No |
| Compliance certificates | RoHS |
| Indication | |
| LED indicators | Yes |
| Design | |
| LED indicators | Yes |
| Product colour | Black |
| Certification | FCC, CE |
| Internal | No |
| Colour | |
| Product colour | Black |
| Certificates | |
| Certification | FCC, CE |
| Compliance certificates | RoHS |
